Home > Industrial Equipment & Components > Power & Generating Sets > Diesel Generator > Power by Cummins 1000kva Diesel Generator,cummins 1000kva/800kw Generator Set

Power by Cummins 1000kva Diesel Generator,cummins 1000kva/800kw Generator Set

Name: Power by Cummins 1000kva Diesel Generator,cummins 1000kva/800kw Generator Set
Brand: power by cummins 1000kva diesel generator
SKU: 103711249

Power by Cummins 1000kva Diesel Generator,cummins 1000kva/800kw Generator Set thumbnail-1

Power by Cummins 1000kva Diesel Generator,cummins 1000kva/800kw Generator Set photo-1

US$ 94,998 - 99,999 MOQ: 1 Set

Key Specifications

Get Latest Price

Place of Origin:

Fujian, China

Brand Name:

power by cummins 1000kva diesel generator

Model Number:

BMC series

Contact Supplier Request Quote Chat Now

Elephant Tech Fuzhou Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Fuzhou Port

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Fujian, China

Brand Name power by cummins 1000kva diesel generator

Model Number BMC series

Output Type AC Three Phase

Speed 1,500/1800rpm

Frequency 50/60Hz

Rated Power 1000kva

Rated Voltage 400/230v

Rated Current from 30A to 2280A

power by Cummins 1000kva diesel generator with CE ISO EPA

Genset Model	Prime Power		Standby Power		Engine Model	Alternator Model
Genset Model	kW	kVA	kW	kVA	Cummins	Marathorn
BMC25M	20	25	22	27.7	4B3.9-G2	GM-20-4
BMC37M	30	37.5	32	40	4BT3.9-G2	GM-30-4
BMC50M	40	50	45	57	4BTA3.9-G2	MP-40-4
BMC93M	75	93	80	100	6BT5.9-G2	MP-75-4
BMC112M	90	112.5	100	125	6BTA5.9-G2	MP-90-4
BMC130M	100	130	112	140	6BTAA5.9-G2	MP-104-4
BMC175M	140	175	155	193	6CTA8.3-G2	MP-140-4
BMC200M	160	200	180	225	6CTAA8.3-G2	MP-160-4
BMC250M	200	250	220	275	6LTAA8.9-G2	MP-200-4

BMC250M	200	250	220	275	NT855-GA	MP-200-4
BMC275M	220	275	250	312.5	NTA855-G1A	MP-220-4
BMC312M	250	312.5	275	344	NTA855-G1B	MP-250-4
BMC337M	270	337.5	300	375	NTA855-G2A	MP-270-4
BMC375M	300	375	330	412.5	NTAA855-G7	MP-300-4
BMC405M	324	405	360	450	NTAA855-G7A	MP-320-4
BMC388M	310	388	340	425	KTA19-G2	MP-320-4
BMC450M	360	450	400	500	KTA19-G3	MP-350-4A/s
BMC500M	400	500	440	550	KTA19-G4	MP-400-4A/s
BMC560M	448	560	500	625	KTAA19-G5	MP-480-4A/s
BMC625M	500	625	550	687	KTAA19-G6A	MP-500-4A/s
BMC750M	600	750	660	825	KTA38-G2	MX-600-4
BMC900M	720	900	800	1000	KTA38-G2A	MX-750-4
BMC1000M	800	1000	880	1100	KTA38-G5	MX-850-4

^{1) Standard configuration of gensets:}^{a) Engine: Cummins diesel engine
b) Engine type: water-cooled, in line four-stoke, Humit cylinder liner,
direct injection
c) Alternator: Sta,ford brushless alternator}

^{2) Control system:}^{a) Automatic alarm system: the unit has the acousto-optics alarm
system and arrestor for any situation as the start defeat, the water
is over temperature, the oil pulls down, over speed, over load and
over current
b) Operation display:
i) Unit voltage, tri-phase load current and frequency display
ii) Water temperature, oil pressure display
iii) Fuel level, fuel temperature display
iv) Audible and visual alarm lamps and buzzers}

^{19) Starting system: DC alternator is used to start engine
20) Short circuit protection: MCCB air switch
21) Cooling system: combined cooling water tank fitted to meet the
requirement of radiation at ambient temperature 40°C
22) Filter system: oil, fuel and air filter
23) Accessories: exhaust elbow, bellow, muffler}

^{3) Supply standard collocation:}^{a) Diesel engine with all accessories, 3 filter, electric systems
b) Alternator
c) Steel structure
d) Fan and water tank cooling system
e) Flange connector
f) 12 / 24V starting motor and charge engine
g) Air cleaner, fuel cleaner, oil cleaner
h) On-board control panel
i) MCCB air conservation switch
j) 12 / 24V starting accumulator and Battery line
k) Set shock absorber
l) High-efficient silencer}

Guaranty:

Guarantee for one year or 1000 hours (whichever comes first) from ex-factory date. During the guarantee period, our Boomaster will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials, except the damage caused by customer's incorrect manmade operation. After expiration, our company will provides cost spare parts maintenance for genset.
