Cummins engine Open Diesel Generator Set 200KVA
Generator & Engine Details
| Genset model | C-200 |
| Prime output(kw/kva) | 160/200 |
| Stand output(kw/kva) | 176/220 |
| Type: | 6CTAA8.3-G2 |
| Power(Kw) | 183 |
| Cylinder numbers(L) | 6 |
| Instrument for adjusting speed | electricity adjust |
| Standar parts: | storage batter. 8hours the fuel tank.Emergency stop switch.shock absorbers. radiator.silencer,drain outlet ,fuel systerm etc |
| Additional Part: | Digital Control Panel and Genset protection |
| Noise (db) | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
| Dimension(L*W*H)mm | 2200*850*1500 |
| Weight(Kgs) | 1900 |
| Dimension(L*W*H)mm | 2400*1100*1700 |
| Weight(Kgs) | 2200 |
Alternator Details
| Altenrator model: | STG274H |
| Rated output(KVA): | 160/200 |
| Bearing | single |
| Coupling | Direct |
| voltage regulation | 0.50% |
| Characteristic | Brushless .Self Excitation .With AVR. Stamford Model 3Phase Class:H IP23 |
| Rated voltage: | 230/400V(any voltage for 110v-760v) |
| Rated frequency: | 50Hz |
Generator set paremeters:
(1)Features Specifications: Silent Diesel Generator
Technical parameters of Engine:
Rated Voltage: 230/400V(Adjustable)
Rated Frequency(Hz): 50/60(Adjustable)
Start mode: DC24V electric start
Voltage Control: AVR
Insulation: H
Protection: IP23
Governor type: Electronic governing
(2)Technical parameters of Alternator:
Brand: Stamford
Frequency fluctuation: 0.5%
Power range: 160KW/200KVA
Frequency regulation: 0.5%(Stable)
(3)Technical parameters of Control Panel:
Start or stop generator set Electrical/Automatically
Generator over/under frequency protection
Generator over/under/unbalance voltage protection
Self-protection for lower oil pressure, high water temperature, over-speed and over-current.
Available for remote control
Guaranty:
Guarantee for one year or 1000 hours (whichever comes first) from ex-factory date. During the guarantee period, our Boomaster will provide the free easy-damaged spare parts for problems caused by our quality of production or raw materials, except the damage caused by customer's incorrect manmade operation. After expiration, our company will provides cost spare parts maintenance for genset.
2.Shipping and payment
MOQ |
1 set |
Delivery Clause |
FOB Fuzhou |
Terms of payment |
T/T, L/C at sight |
3.Company tour
4.Our advantage
.Leading Professional manufacturer of power generator
.Certification:CE EPA ISO IEC
.Fast delivery:we will do our best to meet your requirement when you need it.
.Product quality :Famous high quality engine.we offer spare parts.
.OEM is warmly welcomed
5.Certification:CE ISO EPA
