China Quanchai Engine 8kw Portable Electric Generator
- 300 Set / Sets per Month
- Fuzhou
- T/T
Product Details
Place of Origin: | Fujian, China | Brand Name: | Boomaster | Model Number: | China Quanchai Engine 8kw Portable Electric Generator |
Output Type: | AC Three Phase | Speed: | 1500RPM,1800RPM | Frequency: | 50HZ,60HZ |
Rated Power: | 10-5000kva | Rated Voltage: | 220/380V,230/400V,110/220V,240/400V | Rated Current: | 36-5000AMP |
Product Description
China Quanchai Engine 8kw Portable Electric Generator
Product Overview | |
1) Brand-new engine,w/start motor. | |
2) Brushless alternator,single bearing,flange connection,IP23,H insulation class,with AVR. | |
3) Auto control panel with LCD display. | |
4) Engine mounted battery-charging alternator,Genset with battery charge of main supply. | |
5) Circuit Breaker,Exhaust Silencer. | |
6) Copper Radiator for 40°C ambient temperature and double-deck cooling,with fan guard and front guard. | |
7) Anti-vibration pads fixed between engine/alternator and base frame to ensure the compete genset running stable. | |
8) Skid-mounted bottom 8 hours fuel tank. | |
9) Extemal recessed emergency stop button for extra safety. | |
10)Optional:Soundproof,ATS(automatic transfer switch),AMF panel,Trailer,Parallel system. | |
China Quanchai Engine 8kw Portable Electric Generator | |
Genset Specification | |
Genset Model | BQ-12 |
Prime Power(Kw/Kva) | 810 |
Frequency | 50Hz |
Structure type | Open or Soudproof |
Dba"@7m | silent genset 55-78 dba @ 7m , open type75-98 dba @7m |
Engine Model | QC385D |
Alternator Model | STG164C |
Open type DimensionL*W*H(mm) | 1600x700x900 |
Weight(Kg) | 420 |
Silent type DimensionL*W*H(mm) | 1660x880x950 |
Weight(Kg) | 520 |
Engine Detail | |
Manufacturer | Quanchai engine Co.,Ltd |
Model | QC385D |
Engine speed | 1500rpm |
Engine power | |
…………Prime power | 11KW(50Hz) |
Type | vertical,4cylinder,in-line,water-cooled,four-stroke |
Aspiration | Naturally aspirated |
Governor | electrical |
Bore*Stroke | 85*90mm |
Displacement | 1.532L |
Alternator Detail | |
Model | STG164C |
Output power(Kw/Kva) | 1012 |
Number of phase | 3 |
Power factor(Cos Phi) | 0.8 |
Number of Pole | 4 |
Exciter type | Shunt |
Insulation class | H |
Voltage regulation | 0.50% |
Total haarmonics (TGH/THC) | 4% |
Wave form:Nema=TIF | 50 |
Wave form:I.E.C=THF | 2% |
Bearing | single |
Coupling | Direct |
Generator soundproof/Silent and canopy
Ø Excellent ventilation
Ø Black finish stainless steel locks and hinges
Ø Zinc plated or stainless steel fasteners
Ø Body made from steel components treated with polyester powder coating
Ø Two large doors on either side
Ø Radiator fill access plate
Ø Fully guarded cooling fan and battery charging alternator
Ø Fuel fill and battery access via lockable access doors
Ø Emergency stop button on canopy exterior
Ø Lube oil drain and radiator drain to exterior
Ø Control panel viewing window
Ø Lifting points on base frame
Ø 1m<80DBA / 7m<70DBA
Ø Do the full power load test for five hours before package.
Ø One year or 1000 working hours, whichever comes first, global warranty for Cummins. Deutz, UK P, Volvo, Daewoo.
Ø After expiration, we provide spare parts maintenance
