SALZER SA16 3-4 Changeover Switches 16A, 25A, 32A, 63A, 125A, 160A (TUV,CE and CB Approved )

Specifications

Changeover Switches
1) Current rating: 16A
2) TUV,CE and CB Approved
3)Function: A-0-M

SALZER SA16 3-4 Changeover Switches 16A, 25A, 32A, 63A, 125A, 160A (TUV,CE and CB Approved )





SA Cam Switch

Type	SA16, SA25, SA32, SA63, SA125, SA160
Current	16A, 25A, 32A, 63A, 125A, 160A
Max. Voltage	690VAC
Pole	1Pole, 2Pole, 3Pole, 4Pole
Plate Size	M1 (48X48mm), M2 (64x64mm), M3 (88x88mm)
Faceplate	A-0-M
Degree of Rotation	30°, 45°, 60°, 90°
Ingress Protection	16A and 25A has IP20 with finger protection.









The cam switch is mainly applicable to circuit of 690VAC and below, 50/60Hz. The switch has 6 current ratings: 16A, 25A, 32A, 63A, 125A and 160A. There is finger protection for current of 16A, 25A and 32A.
Switches 16A to 32A have 2 to 12 positions and 1 to 12 stages with many different panels and handles. Switches 63A to 160A have 2 to 12 positions and 1 to 8 stages.
The degree of rotation: 30°, 45°, 60°, 90°
Function: Ammeter, Voltmeter, OFF-ON, 0-1, 1-0-2, A-O-M, FOR-OFF-REV, O-Y-Δ, Δ-Y-O-Y-Δ, 0-1-Star, Multi-step switches and so on
