Home > Products > Marine generator > marine genset withh boat engines
marine genset withh boat engines
USD $5,000 - $50,000
/ Set
1 Set(Min.Order)
- 500 Set / Sets per Month
- FUZHOU
- T/T
You May Like
Product Details
| Place of Origin: | Fujian, China | Brand Name: | Cummins | Model Number: | MC-100 |
| Output Type: | AC Three Phase | Speed: | 1500/1800RPM | Frequency: | 50/60HZ |
| Rated Power: | 100KVA | Rated Voltage: | 230/400V |
Product Description
Specifications
marine genset withh boat engines1.Engine model:Cummins 6BT5.9-GM83
2.Alternator:Stamford UCM274D
marine genset withh boat engines
| Main Technical Data of 100KVA Cummins Marine Generator | ||||
| Model | MC-100 | |||
| Prime Power | 100KVA | |||
| Standby Power | 110KVA | |||
| Rated Voltage | 400/230V | |||
| Rated Current | 135A | |||
| Weight | 1000kg | |||
| Overall Dimension | 2050×830×1190mm | |||
| Main Technical Data of Engine | ||||
| Brand | CUMMINS | |||
| Model | 6BT5.9-GM83 | |||
| Prime Power | 83KW | |||
| Governor Type | Electronic | |||
| Cylinder Type | 6 cylinder in line | |||
| Cooling Method | By heat exchanger | |||
| Bore × Stroke | 102×120 mm | |||
| Compression Ratio | 17.0:1 | |||
| Displacement | 5.9L | |||
| Starting Method | 24DCV | |||
| Fuel Consumption | 212g/kw.h | |||
| Main Technical Data of Alternator | ||||
| Brand | Boomaster | STAMFORD | ||
| Model | TFW2-H-80 | UCM274D | ||
| Prime Power | 100KVA | 100KVA | ||
| Excitation Mode | Brushless, self-exciting | Brushless, self-exciting | ||
| Prime Voltage | 400/230V | 400/230V | ||
| Frequency | 50 HZ | 60 HZ | ||
| Power Factor | 0.8(lagging) | 0.8(lagging) | ||
| Phase/Wire | 3 phase 4 wires | 3 phase 4 wires | ||
| Insulation Grade | H | H | ||
| Protection Class | IP22 | IP23 | ||
Certificate:
Contact Us
- Elephant Tech Fuzhou Co., Ltd.
- Contact nameGT Wall
- Phone86-0591-88371591
- AddressTieling Industry Area,Fuzhou,China Fuzhou,Fujian
