Engine for 6BT5.9-GM83 Power by Marine Genset Cummins Marine Diesel Engines Sale Quality Choice
US$ 5,000 - 50,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
6BT5.9-GM83 power by Cummins engine
Model Number:
MC-100
Payment & Shipping
Payment Methods:
Port of Shipment:
FUZHOU
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Cummins Engine for 100kw Cummins Marine GeneratorUS$ 9,000 - 10,000MOQ: 1 Set -
100kva Marine Generator Set for Cummins EngineUS$ 9,000 - 10,000MOQ: 1 Set
-
Engine for Cummins 150kw Marine Generator Set, Engine for Cummins 150kw Diesel Marine GeneratorNegotiableMOQ: 1 Set
-
Engine for Good Quality Cummins Engine Stamford Marine Generator for Ships on SaleUS$ 5,000 - 10,000MOQ: 1 Set
-
Cummins Engine Marine Diesel Generator/vessels Generator/ship GeneratorUS$ 5,000 - 50,000MOQ: 1 Set
Place of Origin
Fujian, China
Brand Name
6BT5.9-GM83 power by Cummins engine
Model Number
MC-100
Output Type
AC Three Phase
Speed
1500/1800RPM
Frequency
50/60HZ
Rated Power
100KVA
Rated Voltage
230/400V
engine for 6BT5.9-GM83 marine genset cummins marine diesel engines sale
| 6BT5.9-GM83 power by Main Technical Data of 100KVA Cummins Marine Generator | ||||
| Model | MC-100 | |||
| Prime Power | 100KVA | |||
| Standby Power | 110KVA | |||
| Rated Voltage | 400/230V | |||
| Rated Current | 135A | |||
| Weight | 1000kg | |||
| Overall Dimension | 2050×830×1190mm | |||
| Main Technical Data of Engine | ||||
| Brand | CUMMINS power | |||
| Model | 6BT5.9-GM83 | |||
| Prime Power | 83KW | |||
| Governor Type | Electronic | |||
| Cylinder Type | 6 cylinder in line | |||
| Cooling Method | By heat exchanger | |||
| Bore × Stroke | 102×120 mm | |||
| Compression Ratio | 17.0:1 | |||
| Displacement | 5.9L | |||
| Starting Method | 24DCV | |||
| Fuel Consumption | 212g/kw.h | |||
| Main Technical Data of Alternator | ||||
| Brand | Boomaster | STAMFORD | ||
| Model | TFW2-H-80 | UCM274D | ||
| Prime Power | 100KVA | 100KVA | ||
| Excitation Mode | Brushless, self-exciting | Brushless, self-exciting | ||
| Prime Voltage | 400/230V | 400/230V | ||
| Frequency | 50 HZ | 60 HZ | ||
| Power Factor | 0.8(lagging) | 0.8(lagging) | ||
| Phase/Wire | 3 phase 4 wires | 3 phase 4 wires | ||
| Insulation Grade | H | H | ||
| Protection Class | IP22 | IP23 | ||
