engine for 6BT5.9-GM83 power by marine genset cummins marine diesel engines sale Quality Choice

FOB Price

USD $5,000 - $50,000 / Set

1 Set(Min.Order)

Product Details

engine for 6BT5.9-GM83 marine genset cummins marine diesel engines sale

6BT5.9-GM83 power by Main Technical Data of 100KVA Cummins Marine Generator
Model	MC-100
Prime Power	100KVA
Standby Power	110KVA
Rated Voltage	400/230V
Rated Current	135A
Weight	1000kg
Overall Dimension	2050×830×1190mm
Main Technical Data of Engine
Brand	CUMMINS power
Model	6BT5.9-GM83
Prime Power	83KW
Governor Type	Electronic
Cylinder Type	6 cylinder in line
Cooling Method	By heat exchanger
Bore × Stroke	102×120 mm
Compression Ratio	17.0:1
Displacement	5.9L
Starting Method	24DCV
Fuel Consumption	212g/kw.h
Main Technical Data of Alternator
Brand	Boomaster	STAMFORD
Model	TFW2-H-80	UCM274D
Prime Power	100KVA	100KVA
Excitation Mode	Brushless, self-exciting	Brushless, self-exciting
Prime Voltage	400/230V	400/230V
Frequency	50 HZ	60 HZ
Power Factor	0.8(lagging)	0.8(lagging)
Phase/Wire	3 phase 4 wires	3 phase 4 wires
Insulation Grade	H	H
Protection Class	IP22	IP23

Certificate:

Elephant Tech Fuzhou Co., Ltd.: Contact nameGT Wall; Phone86-0591-88371591; AddressTieling Industry Area,Fuzhou,China Fuzhou,Fujian
