Specifications
model of thermoelectric power plant1,Provide installation guide
2,Efficient,environment friendly
3,International standard
CFB Biomass Fired Boiler
Adopting high temperature cyclone separator circulating fluidized bed combustion, cleaner and more efficient.
Both straw fired only and mixed with coal fired, more economic and more flexible.
Adopting a unique heating surface layout, boiler corrosion resistance performance enhancements, more secure and more reliable.
Straw crushed before getting into the furnace, conveying system debugging, reorganizes, running more stable more fluid.
As the use of circulating fluidized bed forms, fouling phenomena greatly reduced
Wide applicability of fuel:cotton stalks, corn stalk, broken twigs, wood chips, wood sugar residue, rice shell and solid waste.
ItemModel |
SHX10-1.25-A SHX10-1.6-A SHX10-2.5/400-A |
SHX15-1.25-A SHX15-1.6-A SHX15-2.5/400-A |
SHX20-1.25-A SHX20-1.6-A SHX20-2.5/400-A |
SHX25-1.6-A SHX25-2.5/400-A |
SHX35-1.6-A SHX35-2.5/400-A |
|
Rated capacity t/h |
10 |
15 |
20 |
25 |
35 |
|
Rated working pressure Mpa |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
1.25/1.6/2.5 |
1.6/2.5 |
1.6/2.5 |
|
Rated steam temperature °C |
193/204/400 |
193/204/400 |
193/204/400 |
204/400 |
204/400 |
|
Rated feed water temperature °C |
105 |
105 |
105 |
105 |
150 |
|
Design fuel |
Soft coal,lean coal,Anthracite,Biomass |
|
||||
Design thermal efficiency % |
86.68 |
87.2 |
88.5 |
88.7 |
89.5 |
|
Smoke extraction temperature °C |
170 |
160 |
150 |
160 |
160 |
|
Transportation weight of Max. parts Kg |
5320 |
2567 |
5000 |
6935 |
7130 |
|
Outside dimensions of after-installed(LxWxH)M |
10.28x8.6x8.62 |
11.5x8.6x10.5 |
13x8.7x12.5 |
14.4x8.7x12.5 |
23.6x8.9x20.9 |
|
Notes:This form only for your reference,if any changed,please refer to Ex-factory technical documents. |
||||||
