Specifications
power plant boilerIndustrial Circulating fluidized bed boiler
power station Circulating fluidized bed boiler
the combustion process can achieve direct desulfurization, desulfurization efficiency, and economy of technical equipment simple.
* coal combustion and wide adaptability and high efficiency, low quality coal suitable for low calorific value.
* discharge of ash activity, and easy to realize the comprehensive utilization of ash no secondary pollution.
* line regulation range, low compliance may be reduced to about 30% of full load
ItemModel |
EPG-35/3.82-M EPG-35/5.3-M |
EPG-75/3.82-M EPG-75/5.3-M |
EPG-130/3.82-M EPG-130/5.3-M |
EPG-220/9.8-M |
|||||
Rated capacity t/h |
35 |
75 |
130 |
220 |
|||||
Rated working pressure Mpa |
3.82/5.3 |
3.82/5.3 |
3.82/5.3 |
9.81 |
|||||
Rated steam temperature °C |
450/500 |
450/500 |
450/500 |
540 |
|||||
Rated feed water temperature °C |
150 |
150 |
150 |
215 |
|||||
Boiler heating ares m2 |
radiation heating surface |
188 |
380.3 |
777.39 |
858 |
||||
Mixes-heating surface |
- |
- |
- |
242 |
|||||
Superheater |
345.5 |
633 |
1089.5 |
2840 |
|||||
Economizer |
663 |
1448 |
2721.98 |
4303 |
|||||
Air preheater |
746 |
1743 |
2514.5 |
8746 |
|||||
Fluidized bed area m2 |
4.43 |
7.7 |
15.2 |
24.556 |
|||||
Design coal type |
Soft coal,lean coal,Anthracite, |
||||||||
Design thermal efficiency % |
88.3 |
90 |
90 |
89.2 |
|||||
Grain size of coal mm |
≤10 |
≤10 |
≤8 |
0~10 |
|||||
Grain size of desulfurizer mm |
≤2 |
≤2 |
≤1.5 |
0~1.5 |
|||||
Desulfurization efficiency % |
≥80 |
≥80 |
≥90 |
≥90 |
|||||
Ca/S Ratio |
2.5 |
2.5 |
2.5 |
2.5 |
|||||
Hot air temperature(primary/secondary air) °C |
130/120 |
145/135 |
207/201 |
231/235 |
|||||
Smoke extraction temperature °C |
150 |
150 |
~140 |
135 |
|||||
Transportation weight of Max. parts Kg |
10488 |
15538 |
18485 |
61718 |
|||||
Outside dimension of after-installed(LxWxH) M |
2.7x9.2x14.9 |
33.85x12x16.25 |
43.2x11.85x20.93 |
24.7x23x48.9 |
|||||
| Notes:This form only for your reference,if any changed,please refer to Ex-factory technical documents. | |||||||||
