High Quality Factory Price DZL Series Biomass Fired Steam Boiler For Sale
Dear Customer:
Welcome to our website and hope our products will make you satisfied .
We think creatively,design bravely,manufacture precisely and loyalty to
our customers. And we have our own factory. So we can produce the products
according to customer requirements .
Give us a negotiate chance and we will yield you a surprise .
Yours,
EPCB
n Adopt high-performance heat transfer components of a threaded pipe, with a reasonable gas flow rate, the boiler thermal efficiency of the high professional standards than the state 6-8 percentage points.
n Convex tube plate, thread to make pot pipe based elastomer with the airfoil stack, completely avoid the traditional high-temperature pyrotechnic tube plate cracking defects.
n Adopt inertial separation of dust furnace supplemented by high-performance multi-collector, so that the concentration of dust emission boiler to meet the demand for a class, reasonable structure of the boiler does not need a steel frame can support the weight of its own.
n Adopt saving energy, strong radiation furnace arch, can guarantee the stability of bituminous coal or anthracite combustion.
n Adopt high standard, high-quality auxiliary equipment, accessories and automatic control equipment, boiler guarantee security, stability operations.
n Boiler capacity is 1-35 t/h (0.7-29MW).
| DZL series Biomass-fired steam boiler technique parameter | ||||||||
| ItemType | DZL1-1.0-M DZL1-1.25-M | DZL2-1.0-M DZL2-1.25-M | DZL3-0.7-M DZL3-1.25-M | DZL4-1.25-M | DZL6-1.25-M | DZL8-1.25-M | DZL10-1.25-M | |
| Rated capacity t/h | 1 | 2 | 3 | 4 | 6 | 8 | 10 | |
| Rated steam pressure MPa | 1.0/1.25 | 1.0/1.25 | 0.7/1.25 | 1.25 | 1.25 | 1.25 | 1.25 | |
| Rated steam temperature ℃ | 184/194 | 184/194 | 170/194 | 194 | 194 | 194 | 194 | |
| Feed water temperature ℃ | 20 | 20 | 20 | 20 | 20 | 60 | 105 | |
| Heated area m2 | radiation convection | 4.55/20.12 | 7.8/41.5 | 9.5/50.6 | 11.9/79 | 17.4/108.1 | 25.7/172.1 | 25/237.6 |
| Boiler thermal efficiency % | 80 | 80 | 81 | 81 | 83 | 85 | 87 | |
| Fuel consumption kg/h | 179 | 358 | 531 | 707 | 1036 | 1382 | 1648 | |
| Effective area of grate m2 | 1.8 | 3.04 | 3.34 | 5.14 | 8.12 | 10.9 | 12 | |
Largest transportation size mm | length | 4876 | 5290 | 5360 | 6258 | 6630 | 7486 | 7600 |
| width | 1800 | 2240 | 2240 | 2700 | 3150 | 3200 | 3200 | |
| height | 2870 | 3400 | 3500 | 3814 | 4186 | 3650 | 4000 | |
| Weight of largest parts of boiler (t) | 13.5/14.2 | 20.8/21.9 | 22.1/23 | 29 | 32 | 35 | 47 | |
Our Services:
1. 100%safety, running stably, excellent water level and pressure control, fully automatic operation.
2. Boiler running life > 20years.
3. Good after-sale service. It is free for you to get the damaged spares in warranty period (1 year) if there is any question. Assure that we can supply you spares in boiler’s all life.
4. We can arrange engineer to your company for installation and commissioning and training. If you need us at any time, we can send our technicians and prepare in a short time.
5. Special paint is used after assembly. Paint is particularly used in your climate area, which is anti-corrosion, anti-abrasion and color-fastness.
Why do you choice our boiler?
1. Lower dust emission & SO2 emission & NOx emission, dust emission concentration < 30mg/m3
SO2 & NOx emission concentration < 18mg/m3
2. We supply 2 units Water Pump (one duty one standby) which from the famous pump manufacturer.
3. Boiler can achieve automatic temperature control & pressure control & feed water control & feed fuel control & safety indication.We also freely supply you a set of inner parts of Electric controller for standby.
4. Boiler with stainless cladding, anti-corrosion & anti-rust & beautiful appearance.
5. Comprehensive after-sales service. We can design layout drawings of boiler system according to your actual requirement.Also can dispatch engineer to guide installation & commissioning.
Q: Are you manufacturer?
A: Yes, we are manufacturer. Our factory is in Pingdu Qingdao established in 1993.
Q: Do I get guarantee of products?
A: Yes, every product is 1 year quality warrantee under customer correct using the products.
Q: Do you have any Certificate?
A: Yes. Each of our boiler has China GB certificate. If you need CE ASME or AS, we can help you to get it.
Q: How to buy it?
A: Please contact me by email or online, let me know your factory situation, I will give you some advice which model mostly suitable to you.
Q: What about the delivery?
A: We have shipping agent can choosing the cheapest and fastest delivery. FOB,CIF, C&F or EXW are no problem for us
Q: How can I pay you?
A: T/T, LC is very well used.
Q: What about the production?
A: Produce time is 20~25days for <6Ton boiler, 25~40days for >8Ton boiler.
Q: Could you offer some wear parts?
A: Yes, some chain grate bars, electric equipments in control panel box for example.
Q: What about the maintenance?
A: I will offer you the timely maintenance way sheet after installation of the boiler mainly parts.
