D1319-1B Conventional Pipe Threading Oil Country Lathe Price

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

Type:

Horizontal

CNC or Not:

Normal

Dalian R&C Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Dalian

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Horizontal

CNC or Not Normal

Automatic Grade Manual

Max. Swing Diameter 630mm

Place of Origin Liaoning, China

Brand Name R&C

Model Number D1319-1B

Voltage 380V

Power(W) 7.5 kw

Weight 4300kg

Certification ISO9001&CE

After-sales Service Provided Engineers available to service machinery overseas

D1319-1B Conventional Pipe Threading Oil Country Lathe Price

Product Description

Specification and Data
Items	D1313-1B	D1319—1B	D1322	Unit
Guideway width	490	490	490	mm
Max.swing over bed	630	630	630	mm
Max.swing over carriage	340	340	340	mm
piece length	1500/3000	1500/3000	3000	mm
The actual machining length	1350/2850	1350/2850	1350/2850	mm
Hole through spindle	130	200	225	mm
cessing Pipe diameter	126	196	219	mm
Number of spindle speed changes	18 steps	12 steps	12 steps	steps
Range of spindle speed changes	12~640	24~300	24~300	r/min
Range and number of inch thread	28~2/40	28~2/40	28~2/40
Range and number of metric thread	1~14/24	1~14/24	1~14/24
Power of main motor	11	11	11	kw
cessing length of taper ruler	500	500	500
Rapid traverse speed	6000	6000	6000	mm/min
Processing workpiece precision	IT7	IT7	IT7
Workpiece surface roughness	Ra1.6	Ra1.6	Ra1.6	Ra1.6
Machine net weight	4200	4300	5300	kg
Max. load weight	2000	2000	2000	kg
