CKA61100A Bench Hobby Lathe Cnc

Dalian R&C Machinery Co., Ltd.

US$ 10,000 - 200,000 MOQ: 1 Set

Key Specifications

Condition:

New

Type:

Other, flat bed

CNC or Not:

CNC

Payment & Shipping

Payment Methods:

Port of Shipment:

dalian

Delivery Detail:

Delivery time depends on order quantity.

Condition New

Type Other, flat bed

CNC or Not CNC

Automatic Grade Automatic

Max. Swing Diameter 1000

Place of Origin Liaoning, China

Brand Name R&C

Model Number CKA61100A

Voltage 380V

Power(W) 50HZ

Dimension(L*W*H) 3455*2020*2000(1000)

Weight 5600 KG

Certification ISO9001,CE

After-sales Service Provided Engineers available to service machinery overseas

CKA61100A Bench Hobby Lathe Cnc

IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER MACHINES >> PACKING >> R&C

Index	Unit	CKA6163A/6180A/61100A
Max swing diameter over bed	mm	630/800/1000
Max work piece length	mm	1000/1500/2000/3000/4000/5000
Max machining length	mm	Vertical 4 station 785/1245/1845/2745/3785/4745 Horizontal 6 or 8 station 690/1140/1740/2640/3660/4640
Max machining diameter	mm	Vertical 4 station 630/800/1000 Horizontal 6 station 570/570/570 Horizontal 8 station 620/620/580
Bed guide way width	mm	550
Spindle bore diameter	mm	110
Spindle taper		Metric 120
Spindle head		A2-6
Tailstock sleeve diameter	mm	100
Tailstock sleeve travel	mm	240
X cutting force	N	2500
Z cutting force	N	5000
Horizontal quick feed	Mm/min	6000
Vertical quick feed	Mm/min	10000
Location accuracy	mm	X 0.03 Z 0.04/0.045/0.050
Machine size(LWH)	mm	For 630 and 800 type 345520201805(1000) 390520201805(1500) 450520201805(2000) 540520201805(3000) 645520201805(4000) 753520201805(5000) For 1000 type 345520202000(1000) 390520202000(1500) 450520202000(2000) 540520202000(3000) 645520202000(4000) 753520202000(5000)
Machine weight	kg	For 630 type 4800/5100/5600/5900/7100/8100 For 800 type 5300/5600/6100/6400/7600/8600 For 1000type 5600/6000/6500/6800/8200/9200
