Home > Manufacturing & Processing Machinery > Machine Tools > CNC Machine Tools > VS80160 5 Axis Cnc Machine Center From Factory
US$ 290,000 - 350,000
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Vertical
Place of Origin:
Liaoning, China
Payment & Shipping
Payment Methods:
Port of Shipment:
DALIAN
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
VS655 Smart Mini 5 Axis Cnc RoutersUS$ 40,000 - 68,000MOQ: 1 Set -
VS655 Cheap Cnc 5 Axis Machine Center VmcUS$ 40,000 - 68,000MOQ: 1 Set
-
VS655 Cheap Mini 5 Axis Cnc Machine CenterUS$ 40,000 - 68,000MOQ: 1 Set
-
VS5080 3 Axis or 4-head Vertical Cnc Machining CenterUS$ 1,000 - 100,000MOQ: 1 Set
-
VS5080 5 Axis or Spindle Aluminum Profile End Cnc Milling MachineUS$ 1,000 - 100,000MOQ: 1 Set
Condition
New
Type
Vertical
Place of Origin
Liaoning, China
Brand Name
R&C
Model Number
VS80160
Voltage
380V
Power(W)
15/18.5kw
Dimension(L*W*H)
800*1800 TABLE SIZE
Weight
20 T
Certification
CE ISO BV
Warranty
1 year
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
1.vertical cnc machining center2.Table Size 800*1800
3.Travel: 1600*800*800
4. Max Table Load 2000kg
VS80160 5 axis cnc machine center from factory
| IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C |
|
| IMAGE > SPECIFICATION>MAIN PARTS > OTHER 5AXIS>PACKING>OTHER MACHINES> PACKING > R&C |
Item | VS80160 |
Table size(mm) | 800×1800 |
X/Y/Z travel(mm) | 1600×800×800 |
Embedded rotary table diameter(C axis) | Φ630 |
Max. table loading(Kg) | 2000 |
Distance from spindle nose to table surface(mm) | 220---1020 |
Spindle type | BT40 |
Spindle diameter | 170mm |
Spindle swivel angle B axis | ±110° |
Spindle speed | 8000/10000/12000 |
Tool magazine type | BT40 |
Tool magazine capacity | 24/32 |
Repeatability(mm) | X:0.01 |
Y:0.01 | |
Z:0.01 | |
C axis:0.0015° | |
B axis:0.0015° |
| IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C |
|
| IMAGE >> SPECIFICATION >> MAIN PARTS>> OTHER 5AXIS>> OTHER MACHINES >> PACKING >> R&C |
|
|
|
|
VS555 Machining Area 300x300x300mm TableSwivel ±90° | VS655 Machining Area 600x300x420mm Spindle Swivel ±110° | VS5080 Machining Area 800x500x500mm Spindle Swivel ±110° | VS80180 Machining Area 1800x800x800mm Spindle Swivel ±110° |
| IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING>> R&C |
|
| IMAGE >> SPECIFICATION >> MAIN PARTS >> OTHER 5AXIS >> OTHER MACHINES >> PACKING >> R&C |
|
| COMPANY PROFILE. |
|
| THE CERTIFICATE. |
|
|
