24/48/96/110/220V 100A MPPT solar controller for household 3 years warranty with CE and RS232 interface to communicate
100A MPPT solar controller introduction:
This controller is used for off-grid solar power systems(independent system),
Especially suitable for small off-grid solar power control system,automatically adjust the charging and discharging .
100A MPPT solar controller performance features:
1.Excellent thermal design and air cooling control
2. Efficient way of PWM charging
3. Variety of load control method, enhanced the flexibility of the system
4. Battery charging parameters can be set up
5. Any combination of photovoltaic module and storage battery reverse automatic protection function, no damage to any device
6. Using traditional LCD liquid crystal display and keyboard design, convenient check the running parameters of the controller, can bring the output, need to customize
100A MPPT solar controller technical parameters:
Model |
NFYG24V-200A |
NFYG48V-200A |
NFYG96V-200A |
NFYG120V-200A |
NFYG240V- 200A
|
Solar rated charge current(A) |
100 |
||||
Battery rated voltage(V) |
24 |
48 |
96 |
120 |
240 |
Float voltage(V) |
50 |
100 |
200 |
250
|
450 |
Over voltage(V) |
29.4 |
58.8 |
117.6 |
147 |
294 |
Over recover voltage(V) |
28 |
56 |
112 |
140 |
280 |
Under voltage(V) |
21 |
42 |
84 |
105 |
210 |
Under recover voltage(V) |
24 |
48 |
96 |
220 |
240 |
No-load loss current(A) |
≤0.2 |
||||
Display mode |
LCD & LED |
||||
Display parameters |
Battery voltage,charge current, battery status and capacity |
||||
Worked mode |
Continue |
||||
Worked environment |
Temperature-35~55℃ |
||||
Size (L * W * H) |
355mm*273mm*142mm |
||||
Weight(Kg) |
7.5 |
||||
We are professional to do solar controller ,we can do OEM ODM,If you want to know more info please contact me !
