Double Spiral Shape SiC Heating Element
SiC Heating Element is made from very dense silicon carbide, featuring a return spiral groove allowing connection at
one end. The resistance and allowable surface loadings of the Double Spiral Shape Type are substantially higher than other silicon carbide elements, consequently operating voltages are higher and current draw lower. This feature can lead to significant savings in both control equipment and wiring. Double Spiral Shape elements are energy conserving, convenient and easy to install due to the same-end terminal structure.
When you place an order of the Double Spiral SiC Heating Element, please give following information:
OD (mm): Outer Diameter
HZ (mm): Hot Zone length
CZ (mm): Cold Zone length
OL (mm): Overall Length
If you have the special requirement for the resistance, please tell us!
Order Sample of the Double Spiral SiC Heating Elements
SD Shape: OD=31.7mm, HZ=305mm, CZ=241mm, OL=546mm, Resistance 4.46Ω
Specify as: 31.7/305/546/4.46Ω
Usage of SiC Heating Element
Silicon Carbide (SIC) heating elements can usually make use for furnace which temperature from 600-1600. It can be
directly used in an air atmosphere, without any protection atmosphere. It is extensively used in the fields of metallurgy, ceramics, glass, machinery, analysis test, semiconductor, science & research and so on.
SiC Heating element Packaging:
Plastic paper inside, polyfoam filled, wooden box outside.
SiC Heating element Shipment:
--By DHL/Fedex (Door to door, Home delivery service)
--By Air to your nearest Airport
--By Sea to your nearest Seaport
--By the sellers’ shipping agent
