Home > Instruments & Meters > Meter for Electricity > Energy Meter & Power Meter > PMAC625 Three Phase Digital Network Panel Meter
Negotiable
MOQ: 8 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Pilot
Model Number:
PMAC625
Payment & Shipping
Payment Methods:
Port of Shipment:
Zhuhai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
3 Phase LED Digital Panel Meter With RS485 ModbusNegotiableMOQ: 1 Unit -
PMAC600D Three Phase Voltage Meter, Ampere Meter, Current MeterNegotiableMOQ: 8 Pieces
-
PMAC600E Single Phase Voltmeter, Voltage MeterNegotiableMOQ: 20 Pieces
-
PMAC600E Single Phase Ampere Meter / Current Meter / Panel MeterNegotiableMOQ: 20 Pieces
-
PMAC600E Digital Voltage Meter, Digital Current Meter, Digital Panle MeterNegotiableMOQ: 8 Units
Place of Origin
Guangdong, China
Brand Name
Pilot
Model Number
PMAC625
Measuring Current Range
0-5A
Measuring Voltage Range
0-500V
Accuracy Class
0.5%
Operating Temperature
-20~70degree
Dimensions
96 x 96mm
Specifications
3-phase Digital Network Panel MeterLED display voltage, current, power,
frequency, power factor, kWh, DI/ DO
RS485, Modbus
PMAC625 Three Phase Digital Network Panel Meter
ØSuit for 220V, or 240V (ph-N) low voltage system
ØSimultaneous sampling of Volts and Amps
ØCompact design with all real-time measurement
Ø10 years back-up of integrated energy data
ØLED display, high brightness, auto-scrolling
ØCT primary is programmable
ØPluggable terminals, easy to install
ØPanel size: 96 x 96mm
ØPassword protect
ØStandard: IEC62053-21, CE
Basic Function
PMAC625 measures and display one or more parameters listed below:
ØVoltage—Ua, Ub, Uc, Uab, Ubc, Uca,
ØCurrent—Ia, Ib, Ic, In
ØActive power – Pa, Pb, Pc, ∑P
ØReactive power –Qa, Qb, Qc, ∑Q
ØPower factor—PFa, PFb, PFc, ∑PF
ØFrequency--F
ØActive energy—kWh
ØReactive energy-- kvarh
Optional Function
ØTwo status input ( wet contact)
ØTwo relay alarm output
ØOne RS485 communication
Parameter | Accuracy | Resolution | Measuring Range |
Voltage | 0.2% | 0.01V | 264V(ph-N), 500V (ph-ph) |
Current | 0.2% | 0.001 | CT primary: 0~9,999A CT secondary: 1 A or 5A |
Power | 0.5% | 0.1W/ var | 9,999 kW/ kvar |
Power factor | 0.5% | 0.001 | -1.000~+1.000 |
Frequency | 0.01 | 0.01Hz | 35-65Hz |
Active energy | 1.0% | 0.1kWh | 0-99,999,999.9 kWh |
Reactive energy | 2.0% | 0.1kvarh | 0-99,999,999.9 kvarh |
