High Strength Concrete Test Hammer 60Mpa for Building Structure

Specifications

1.Center rod use imported material, high precision and wear proof:
2.Shell use super hard aluminums, protect instrument from da



     TMTeck Manufacturing LTD. (hereafter “TMTeck”) is a leading NDT manufacturers and suppliers in Beijing China and provides innovative technologies and comprehensive know-how to benefit customers in a lot of countries around the world.Till now,TMTeck has been active in the areas of technology-driven inspection solutions that deliver productivity, quality and safety.

     Began from the Ultrasonic Flaw Detector and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates.



Brief introduction:



Submit to JGJ/T23-2001 technology regulation. The instrument is suitable for testing strength of tall building structure, bridge and concrete component etc.



Trait



1)Center rod use imported material, high precision and wear proof:



2)Shell use super hard aluminums, protect instrument from damage on site work and prolong use life;



3)Pointer slider is outside ring structure, easy to adjust friction, and assure equal friction between pointer slider and axis. And assure the precision of instrument, compare with similar other brand product, it’s good precision, longer use life and better price.







Parameter



Test range: 50~80Mpa



Standard impact energy:9.8J



Stroke of rebound hammer: 140mm



Friction of pointer slider: 0.4N~0.8N



Average rebound value on steel anvil: 83±2



Stiffness of tension spring: 10N/cm



Size: Φ65*486mm



Weight: ≈3.5KG

TMTeck is committed to the maintenance of long-term partnership with our clients by offering unparalleled services, technology advice and assistance. We design and produce a wide range of high performance NDT equipment and accessories. With our continued emphasis on customer focus and global competitiveness, TMTeck has always been one of the top tier of world class companies when it comes to leading in NDT equipment. And we are developing new series products according to the market demand. We can offer good guarantee for our customers.
