Type-in-one Voice Digital Concrete Test Hammer , 785N 2.207J

Specifications

     TMTeck Manufacturing LTD. (hereafter “TMTeck”) is a leading NDT manufacturers and suppliers in Beijing China and provides innovative technologies and comprehensive know-how to benefit customers in a lot of countries around the world.Till now,TMTeck has been active in the areas of technology-driven inspection solutions that deliver productivity, quality and safety.

     Began from the Ultrasonic Flaw Detector and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates.

Brief introduction:

Test hammer HTH-225V submitted to GB /T9138-1988, JJG817-93 and JGJ/T23-2001 standards. The instrument is useful for quality Inspection Company, site testing or sampling and laboratory center, don’t have to manual calculation, machine automatically compute, grade and printing.

Trait:

1)The test hammer is combined with displayer part, easy to operate and make your work efficient.)

2) LCD color screen 176*220 (other manufacturers’ are black and white, low resolution))

3)Large capacity rechargeable lithium battery, economic and environment protection, long use life, better than other market product (one time use battery)

4)No-touch metal reflect grating and reflect compile sensor, better accuracy. (other manufacturer’s are ordinary transmission grating and optical coupler, or carbon film and brush touch sensor)

5)Born with voice service, color screen display and traditional scale, more accurate, in case power off when site work, we still can make use of the scale to continue work. Voice service can make your work efficient. (similar product of other manufacturers’in market no voice service and scale)

6)USB interface, easy to connect with PC

7)The software can set rebound value from upper limit to lower limit, and the abnormal date will be deleted automatically.

8) Equipped with infrared portable printer, on site print test report.

9)Some important components are processed from imported materials, after our excellent processing, the instrument get longer use life, better than other similar products.

Parameter:

1.test range:10-60Mpa

2.standard impact energy:2.207J.

3.rigidity of tension spring:785N/M.

4.stroke of rebound hammer: 75mm.

5.error range for digital displayer:≤±0.5(the difference between displayer and scale)

6.average rebound hammer on steel anvil Rm:80±2.

7.Screen:16bit true color,176*220resolution,5 classes back light choose.

8.Storage:255*100*16=408000 test points, customer can add up to 20 test curves.

9.Power source:3.6V/1300mAH Li battery,charger adapter 5V/2A.under largest back light and shut down the voice, last work 13 hours.

10.Power consumption:largest back light≈100mA(voice shut down).

nnect interface:USB2.0

12.weight:1.1Kg.

Compare between HT225-V digital test hammer and other digital test hammer.

After careful comparing all the test hammers in market. , test hammer manufactured by us is better, and you will find our price is better too.
