Low Cost Modular Ultrasonic Flow Meter(clamp On) TUF-2000M

      TMTeck Manufacturing LTD. (hereafter “TMTeck”) is a leading NDT manufacturers and suppliers in Beijing China and provides innovative technologies and comprehensive know-how to benefit customers in a lot of countries around the world.Till now,TMTeck has been active in the areas of technology-driven inspection solutions that deliver productivity, quality and safety.

      Began from the Ultrasonic Flaw Detector and Coating Thickness Gauge ,now TMTeck has developed more than 10 series of testing instruments, including Ultrasonic Flaw Detector, Coating Thickness Gauge,Hardness Testers,Ultrasonic Thickness Gauge ,their accessories and other NDT instruments. These products are widely used in the analysis of materials that enable our customers to monitor, control and validate their critical processes and applications,also our goods has CE certificates.

Measuring Diagram:

The meter has the advantages of small size, complete functions and low cost. Using guide rail installation, it is suitable to be installed in

instrument box or distribution pane.

Optional types of transducers, measuring range from DN50 ~ DN6000mm. No need to stop water.

Features of the meter:

Working Environment

Basic Parameters

Features of Transducers:

Standard insertion Transducer

• Suitable for the pipeline can be directly welded, like carbon steel and stainless.
• Pipeline thickness: ≤20mm
• Measuring range: DN80~DN6000
• Temperature: -30~160 ℃

Extended insertion Transducer

• Suitable for the pipeline cannot be directly welded, like cement pipe, cast iron, PVC, steel or composite material.
• Pipeline thickness: ≥20mm
• Measuring range: DN80~DN6000
• Temperature: -30~160 ℃

Parallel insertion Transducer

High temperature insertion transducer
