2 stations Sole injection machine
- 30 Set / Sets per Month
- As per request
- T/T Credit Card PayPal
Product Details
Condition: | New | Type: | Tube Head Injection | Style: | Vertical |
Brand Name: | KingKong(JinGang) | Place of Origin: | Guangdong, China | Plastic Type: | Thermoplastic |
Automatic: | No | Injection Weight: | 300grams | Clamping Force: | 70Tons |
Opening Stroke: | 100mm | Power(W): | 28KW | Certification: | CE |
After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
2 stations Sole injection molding machine, out sole injection moulding machine
This machine mainly use to proudce PVC/TPR Strap or outsole or other shoe accessory which weight below 300 grams.
Feature:
1)Vertical 4 pillars Direct Mould Lock with high speed mould clamping;
2)With high pressure sand high speed injection Rate, is special design for footwear component Production, the bes configuration machine for TPR, TPU and TR thin out sole for man or lady.
3)Big injection screw L/D Ratio;
4)Extensible Computer program and automatic lay-out & buit-in wires to meet different full Automatic request.
5)Mould clamping Apply direct composite type mould lock cylinder design, capable of decline clamping and low speed with low pressure clamping. This can greatly last serve life of the muld.
6)Doble injection cylinder system to ensure stable and strong injection.
7) Automatic Self error detected function, easy to figure out the problem.
Technical data:
| Model | Unit | JG-L21-70T |
Injection System | Injection screw | Mm(dia.) | 48 |
Injection pressure | Kgf/cm² | 1137 | |
Injection valume | Cm²/grams | 300 (Maximum) | |
Screw injection distance | Mm | 140 | |
Screw Rotation speed | RPM | 0-180 | |
Injection nozzle Pressure | Tons | 3.5 | |
Nozzle injection distance | Mm | 250 | |
Temperature control | Zone | 4 | |
Clamping force | Tons | 70 | |
Available Mould size | Mm | 400x400 | |
Minimum Available mold thinness | Mm | 50 | |
Maximum Mold height | Mm | 220 | |
Hydraulic system | Maximum pressure | Kgf/cm² | 140 |
Oil pump Capacity | Cc/rev | 53 | |
Motor | Kw | 11(15hp) | |
Heating power | Kw | 5.6 | |
Total loading power | Kw | 16.5 | |
Machine size | M | 1.7x1.3x2.8 |
We can offer All kind of shoe mold along with our machine, as long as get client shoe sample.
Sample:
CE Certificate:
