Home > Products > Hunting Camera > Ltl Acorn 850nm IR LED 12mp MMS game camera with extend antenna for hunting

Ltl Acorn 850nm IR LED 12mp MMS game camera with extend antenna for hunting

FOB Price

US$ 185 - 193 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	SOMAX
Model Number	SM-HC0030

Product Description

Specifications

Model Parameters :MMS hunting camera
Image Sensor :5 Mega Pixels Color CMOS
MMS/SMS/Email via GSM Network,

8500nm IR LED 12mp MMS hunting camera with extend antenna

850nm IR LED ,12mp MMS hunting camera with extend antenna,MMS/SMS/Email via GSM Network,Quad band:850/900/1800/1900MHz ,Camera ,video and camera+video three different model,support to 16gb sd card,trigger time is 1.0S, lower power consumption.

camo and black color are optional,

TECHNICAL SPECIFICATION

Model Parameters :MMS hunting camera

Image Sensor :5 Mega Pixels Color CMOS

Max. Pixel Size :2560*1920

Lens: F=3.1; FOV=52; Auto IR-Cut

IR Flash: 65 Feet/20 Meters

LCD Screen: 48*35.69mm(2.36");480(RGB)*234DOT; 16.7M Color

Operation Keypad: 6 Keys

Memory :SD Card (8MB ~16GB)

Picture Size :5MP/12MP/1.3MP =2560*1920/4000*3000/ 1280*960;

Video Size :640*480: 20fps; 320*240: 20fps

PIR Sensitivity :High/Normal/Low

PIR Sensing Distance :65ft/20m(Below 77F/25C at the Normal Level)

Prep PIR Sensing Angle:Left and right light beams form an angle of 100 degree ; Each lens covers 10

Main PIR Sensing Angle :35

Operation Mode :Day/Night

Trigger Time :1.1 Second (When using the 2G SD card)

Trigger Interval :0sec. - 60min; Programmable

Shooting Numbers :1~3

Video Length: 1-60sec.; Programmable

Camera + Video: First take Picture then Video

Playback Zoom In :1~16 Times

Time Stamp :On /Off; Include serial no., temperature and moon phase

Timer :On /Off; Time Lapse Programmable

Password :4-Digit Numbers

Device Serial No.: 4 digits and 26 alphabets set by yourself

Periodic Shot :1 Second ~ 24 Hours

MMS Picture Size :VGA: QVGA: OFF: Programmable

MMS Numbers :1~99/Day:Not limit: Programmable

Mobile number :1~3

E-mail :0~1 Programmable extensible

Low Battery SMS Alert:Send ”Battery Low” extensible

Power Supply: 4*AA; Expandable to 8*AA (With additional battery box)

External DC Power Supply:Plug Size:4.0*1.7 6~12V(2~1A)

Stand-by Current: 0.4mA Yes Yes

Stand-by Time :3~6 Months(4*AA~8Xaa)

Auto Power Off: Auto power off in 2 minutes while no keypad controlling

Power Consumption:150mA (+350mA when IR LED lights up)

Low Battery Alarm:4.2~4.3V

Interface :TV out (NTSC); USB; SD Card Slot; 6V DC External

Mounting Strap; Tripod Nail

Waterproof IP54

Operation Temperature -22~+158F/-30 ~+70C

Operation Humidity:5% ~ 95%

Certificate FCC & CE & ROHS

Accessories:

Digital camera :1

Additional battery box :1 (With MMS module)

TV AV IN cable:1

USB cable:1

Strap:1

External DC cable (optional): 1

CD:1

Warranty Card:1
