Ltl Acorn LTL-5310A 720P video Trail Hunting Camea

FOB Price

US$ 145 - 150 / Piece

1 Piece(Min. Order)

Port Shenzhen
Payment TermsCredit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	SOMAX
Model Number	LTL-5310A

Product Description

Specifications

Item Parameters Ltl-5310A
Image Sensor 5 Mega Pixels Color CMOS
Max. Pixel Size 2560x1920

The Ltl Acorn 5310 Series (Model Ltl-5310A/MC and Ltl-5310MM) is the third generation of our Ltl acorn scouting camera. Bundled with the MMS-module(Multimedia Messaging Service) battery box (Part # LTL-MM1)standardscouting camera (Part # Ltl-5310MC) can be upgraded to work as a remote

cellular camera. With its highly sensitive Passive Infra-Red (PIR) sensor thecamera detects the sudden change of ambient temperature caused by moving game in a region of interest (ROI), triggers to take pictures/videos,and sends the images via GSM network to the user cell phone or email

account. With newly added SMS remote control feature you can change the related menu of the camera by sending SMS order to the camera in the

specific form of the SMS content.

Programmable 5 or 12-Megapixel high-quality resolution.

With SMS RCP (remote control program) parameters of camera can be changed by SMS sending. If in request, the camera can take picture and send back simultaneously.

No-glow Infrared 940nm LEDs flash range as far as 65 feet, luminance as bright as 850nm.

In â€œCam + Videoâ€ mode, camera takes both pictures and video at every trigger event

Ultra low standby power consumption. Extremely long in-field life (in standby mode, up to 6 months with 8 x AA batteries)

Unique side Prep Sensor design provides wider sensing angle and enhances cameraâ€™s response speed

Perform in the most extreme temperatures from -22Â°F to 158Â°F

Compact size (5 Â½ x 3 Â½ x 2 Â½ inches). Well designed to deploy covertly

Impressively quick trigger time (0.8 second)

In Time Lapse setting, the camera automatically and constantly takes pictures/videos at specified interval. This is very useful when observing plants flowering, birds building nest, or when monitoring unattended properties such as parking lots

With Timer setting on, the camera can be programmed to only work in specified period every day. This feature can work together with Time

Lapse feature

Backpack-looking tree grabber makes mounting and aiming a snap

Serial Number setting enables you to code locations in the photos.This helps multi-camera users identify the location when reviewing the photos

TECHNICAL SPECIFICATION
Item	Parameters	Ltl-5310A
Image Sensor	5 Mega Pixels Color CMOS	Yes
Max. Pixel Size	2560x1920	Yes
Lens	FOV=55Â°; Auto IR-Cut	Yes
Lens	FOV=100Â°; Auto IR-Cut	N/A
IR Flash	65 Feet/20 Meters	Yes
LCD Screen	48x35.69mm(2.36"); 480(RGB)*234DOT; 16.7M Color	Yes
Operation Keypad	6 Keys	Yes
Memory	SD Card (8MB ~16GB)	Yes
Picture Size	5MP/12MP/1.3MP =2560X1920/4000X3000/1280X960;	Yes
Video Size	640x480 320x240 30fps; 1280x720 20fps	Yes
PIR Sensitivity	High/Normal/Low	Yes
PIR Sensing Distance	65ft/20m(Below 77Â°F/25Â°C at the Normal Level)	Yes
Prep PIR Sensing Angle	PIR Sensitivity High/Normal/Low/Off	Yes
Main PIR Sensing Angle	35Â°	Yes
Operation Mode	Day/Night	Yes
Trigger Time	0.8 Second (When using the 2G SD card)	Yes
Trigger Interval	0sec. - 60min; Programmable	Yes
Shooting Numbers	1~3	Yes
Video Length	1-60sec.; Programmable	Yes
Camera + Video	First take Picture then Video	Yes
Playback Zoom In	1~16 Times	Yes
Time Stamp	On/Off; Include serial No., temperature and moon phase	Yes
Timer	On/Off; Time Lapse Programmable	Yes
Password	4-Digit Numbers	Yes
Device Serial No.	4 digits and 26alphabets set by yourself	Yes
Periodic Shot	Time Laps 1 Second ~ 24 Hours	Yes
MMS Picture Size	VGA; OFF Programmable	N/A
MMS Numbers	1~99/Day: Not limit: Programmable	N/A
Mobile number	1 ~ 3	N/A
E-mail	0 ~ 1 Programmable	N/A
Low-Battery SMS Alert	Send â€œBattery Lowâ€	N/A
Power Supply	4xAA; Expandable to 8xAA (With additional battery box)	Yes
External DC	Plug Size: 4.0x1.7	Yes
Power Supply	6 ~ 12V (1 ~ 2A)
Stand-by Current	0.4mA	Yes
Stand-by Time	3~6 Months(4xAA~8xAA)	Yes
Auto Power Off	Auto power off in 2 minutes while no keypad controlling	Yes
Power Consumption	150mA (+650mA when IR LED lights up)	Yes
Low Battery Alarm	4.2~4.3V	Yes
Interface	TV out (NTSC); USB; SD Card Slot; 6V DC External	Yes
Mounting	Strap; Tripod Nail	Yes
Waterproof	IP54	Yes
Operation Temperature	-22~+158Â°F/-30 ~+70Â°C	Yes
Operation Humidity	5% ~ 95%	Yes
Certificate	FCC & CE & ROHS	Yes
