Clay mineral crusher
Application:
The PC series clay mineral crusher is also named hammer mill, which is suitable for mid-hard and light erosive materials, whose pressure resistance strength is no more than 100Mpa and humidity lower than 15%, such as coal, salt, chalk, gypsum, blocks, limestone, etc. The PC-Hammer crusher is suitable for both dry and wet crushing of brittle, medium-hard materials for the mining, coal, metallurgic, construction material, road building, and chemical industries...
Features:
1. It is of various types.
2. It is suitable for crushing maximum, medium and minimum stones.
3. It is easy to be operated.
4. Simple structure; High reduction ratio; Low operation cost; Easy maintenance;
Working Principle:
The motor drives the rotor rotates of this clay mineral crusher at a high speed through the belt, and on the rotor there are series hammers. When the materials get into the working area of hammers, they are crushed by the rotating hammers of the crusher with high rotation speed, the products which are crushed to meet the required size can be discharged by the outlet and become the final products
Technical parameters:
Type |
Rotor Diameter/Length mm |
Rotor Speed r/min |
Feed Size mm |
Max. Input Size |
Output Size mm |
Capacity |
Power |
Weight |
Size |
PC-41 |
φ400/175 |
1000 |
145×270 |
50 |
3 |
0.5 |
5.5 |
0.5 |
812×1056×1315 |
PC-44 |
φ400/400 |
1500 |
145×450 |
100 |
10 |
5~8 |
7.5 |
0.9 |
744×942×878 |
PC-64 |
φ600/400 |
1000 |
295×450 |
100 |
15 |
10~12 |
18.5 |
1.03 |
1054×972×1117 |
PC-66 |
φ600/600 |
1000 |
295×570 |
100 |
10 |
12~18 |
45 |
2.14 |
1315×840×1501 |
PC-86 |
φ800/600 |
1000 |
350×570 |
200 |
10 |
20-25 |
55 |
2.45 |
1515×2586×1040 |
PC-88 |
φ800/800 |
1000 |
350×850 |
200 |
15 |
35-45 |
55 |
3.05 |
1515×2831×1040 |
PC-108 |
φ1000/800 |
1000 |
580×850 |
200 |
13 |
25-40 |
110 |
6.5 |
3206×2210×1515 |
PC-1010 |
φ1000/1000 |
1000 |
580×1060 |
200 |
15 |
40-60 |
132 |
7.59 |
3514×2230×1516 |
