Low Frequency Industry 3 Phase Online UPS 100KVA For Computer Data Center
High reliability
True on-line static bypass technology, to provide strong overload and fault protection device.
Internal manual maintenance bypass, further improve the reliability of continuous operation of the load.
Network management humanity
Communicate with PC by RS232.
Use SNMP adapter, UPS can realize remote network management function.
Parallel redundancy
Can parallel 8 units UPS;
Parallel UPS units can share a battery pack;
Non-fixed master/slave parallel
Pure Sine Wave 100KVA Online UPS Parammeter:
| MODEL-HT | 10KS | 20KS | 30KS | 40KS | 60KS | 80KS | 100KS | 120KS | 160KS | 200KS |
| RATED POWER | 10KVA | 20KVA | 30KVA | 40KVA | 60KVA | 80KVA | 100KVA | 120KVA | 160KVA | 200KVA |
| (VA/W) | 8KW | 16KW | 24KW | 32KW | 48KW | 64KW | 80KW | 96KW | 128KW | 160KW |
| INPUT | ||||||||||
| INPUT VOLTAGE | 380VAC(3 phases) or 190VAC(3 phase) | |||||||||
| VOLTAGE RANGE | 304-456VAC or 152-228VAC | |||||||||
| FREQUENCY | 50/60Hz±5% | |||||||||
| Power Factor | >0.97 | |||||||||
| Max. input current | 18A | 37A | 55A | 72A | 108A | 130A | 160A | 190A | 245A | 310A |
| OUTPUT | ||||||||||
| Voltage | 380VAC/190VAC±1% | |||||||||
| Frequency | Sync to input(line mode),50Hz or 60Hz±0.05 | |||||||||
| Waveform Type | pure sinewave | |||||||||
| Power Factor | 0.8 | |||||||||
| THD | <3% with linear load | |||||||||
| Overload Capability | 110% for 300mins /125% for 10mins /150% for 1min then transfer to bypass & alarm | |||||||||
| Current Crest Ratio | 3:1(max) | |||||||||
| overall efficiency | >90% | |||||||||
| Transfer Time | ||||||||||
| From inverter to battery | 0ms | |||||||||
| Bypass | ||||||||||
| Voltage | 380VAC | |||||||||
| bypass voltage range | ±10%,±15%,±20% adjustable | |||||||||
| Battery | ||||||||||
| Voltage | 384VDC | 432VDC | 480VDC | |||||||
| Recharge Time | 8~10 hrs to 90% of capacity after full load discharge | |||||||||
| LED /LCD Indications | ||||||||||
| LED | Battery level,utility power,inverter,bypass,Fault, overload | |||||||||
| LCD | Input/output voltage,Frequency,battery voltage,load percent,Tempreature | |||||||||
| Communications | ||||||||||
| interface | RS232 SNMP(optional) | |||||||||
| Intelligent Slot | Dry Contact/EPO/SNMP Card (optional) | |||||||||
| Working conditon | ||||||||||
| Temperature | 0~40°C | |||||||||
| Humidity | 0~95%°C non-condensing | |||||||||
| Storage tempreature | -25°C~55%°C | |||||||||
| Acoustic Noise | <55dB | <60dB | <65dB | <70dB | ||||||
| Weight | ||||||||||
| N.W(Kg) | 223 | 260 | 336 | 351 | 497 | 556 | 756 | 901 | 1300 | 1350 |
| G.W(Kg) | 280 | 317 | 393 | 408 | 574 | 633 | 856 | 1001 | 1400 | 1450 |
| W×D×H mm | 555*725*1220 | 800*745*1400 | 1070*745*1400 | 1420*745*1810 | ||||||
| S: long backup | ||||||||||
|
|
Pure Sine Wave 100KVA Online UPS Image:
Produce line
Quality Control Equipment:
Applications:
Computer center,network center,communication system,automation control system or other critical system.
About the company
HKSANTEK'S Quality Policy
Qaulity is a system, quality is a project,it can contains all the activities of the whole factory,HKSANTEK's belief is "behave
ourseleves firstly, then keep the materials &produce in good level, finally assure the products's quality.everyactivity
effect the quality, so every one is the QC staff in factory.
All the running of HKSANTEK Company is compliant with the ISO9001-2008 and ISO 14001-2004
