Hot Mono Solar Panel Module 180Wp With TUV Certificate
- Shanghai
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | STS | |
| Model Number | STS-5M-180P-72 | Material | Monocrystalline Silicon | |
| Size | 1580x808x40 mm | Number of Cells | 72pcs | |
| Max. Power | 180W |
Product Description
hot mono solar panel module 180Wp with TUV certificate
Efficiency 180W solar panel
1. Low voltage-temperature coefficient allows higher power output at high-temperature condition.
2. High efficient, high reliable solar cells ensure our product output stability.
Benefits
1. Manufactured in an ISO9001:2008 certified plant
2. High efficiency, high safety, high reliability
3. Output power tolerance of +/-3%
Warranty
1. 5-years limited warranty on materials and workmanship
2. 25-years limited warranty on power output: 10 years/90%, 25 years/80%
Electrical Parameters
| Maximum power at STC (Pmax) 180W |
| Maximum Power Voltage(Vmp) 36.42V |
| Optimum operating current (Imp ) 4.94A |
| Open-circuit voltage (Voc ) 44.88V |
| Short-circuit current (Isc ) 5.44A |
| Short-circuit current temperature coefficient ( 0.065±0.015)%/°c |
| Open-circuit voltage temperature coefficient -(80±10)mV/°c |
| Peak power temperature coefficient -(0.5±0.05)%/°c |
| NOCT (Air 20°c; Sun 0.8kW/m wind 1m/s) 47±2°c |
| Operating temperature -40°c to 85°c |
| Maximum system voltage 1000V DC |
| Power tolerance ±3% |
International standard package or custom service
1.Reply your inquiry in 24 working hours
