AZ9060M auto right & lift move table laser cutting engraving machine for sale
- 300 Piece / Pieces per Month
- shenzhen
- T/T L/C D/P D/A Credit Card PayPal
Product Details
Condition: | New | Laser Type: | CO2 | Applicable Material: | Acrylic, Crytal, Leather, MDF, Paper, plastic, Plexiglax, Plywood, Rubber, Wood |
Cutting Thickness: | 0-30mm | Cutting Area: | 900mm*600mm | Cutting Speed: | 0-10000mm/min |
CNC or Not: | Yes | Cooling Mode: | Water Cooling | Control Software: | AWC608 |
Graphic Format Supported: | AI, BMP, DST, DWG, DXF, DXP, LAS, PLT | Place of Origin: | Guangdong, China | Brand Name: | Aotopto |
Model Number: | AZ9060M | Certification: | CE, ISO, SGS | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
M-Series Right&Left Moving Table Laser Cutting&Engraving Machine
Series Introduction
Suitable for cutting and engraving fabric easy flat materials that are not easy to evel such as leather, fabric and some large or heavy materials that can be moved easily. Long focal length focus lens helps you get thicker cutting depth.
Features Description
1. Double working tables design
2. Left/right slidable
3.Higher efficiency with receiving / feeding separately
4. Double laser heads
5. Laser power of each head can be controlled by latest designed operating software
6.The best choice for non-metal cutting industry and laser processing workshop
Technical Parameter of M-Series laser machine
Working area | 900 *600mm |
Minimum shaping character | English 1.0 * 1.0mm, Chinese 2.0*2.0mm |
Reposition accuracy | ≤±0.01mm |
Resolution | ≤4000DPI |
Max engraving speed | 0-6400mm/min |
Cutting speed | 0-3400mm/min |
Laser-type | Sealed CO2 laser tube |
Power Adjustment | 0-100% Steeples Control, 0-100% Adjustable in Software |
Laser power | 80W-150W |
Wave length | 10.64um |
Cooling mode | water-cooling and protection system |
Operating temperature | 0-45 degrees Celsius |
Operating humidity | 5%-95%(Free of condensed water) |
Control and Driving | High Speed DSP Control, Stepper Motor High Subdivide Driving |
Gross power | ≤1250W |
Power supply | AC220V/110V±10% 50HZ/60HZ |
Graphic format supported | CDR, BMP, PLT,PCX, DXF,DST,GIF |
Compatible Software | TAJIMA , CorelDraw, AutoCAD, Photoshop |
Applied Materials
Wood, paper, leather, fabric, organic glass, epoxy resin, acrylic, woolen, plastic,
Rubber, Ceramic tile, crystal, Stone, bamboo products and other non-metal materials.
Applicable Industries
The machine is suitable for Garment, leather, stuffed toy, computerized embroidery and clipping industry.
CE-Certification
After-Sales Service & Warranty
1. We provide one year free warranty beyond which we charge only accessory fee and cost;
2. Warranties on laser tubes differentiate due to brands diversities. Contact us to get exact warranty period on your purchase;
1, Get warranty extension with preferential price;
2, Free lifetime remote technique-service via telephone, email, online video, Skype, QQ etc.;
3, Free lifetime training and guidance in our factory;
4, Get operating software CD, U Disc for free;
The following circumstances are exclusive
1, Natural aging of consumables and other parts;
2, Man-made damage due to maloperation against the operation manual;
3, Malfunction and damage caused by repair, transform without permission;
4, Damage caused by fire, flood, voltage anomaly and other force majeure;
5, Other non-product quality damage.
Why choose Aotopto?
About us - Dongguan Aotopto Technology Co., Ltd
AOTOPTO Technology Co., Ltd. is a professional manufacture focusing on providing solutions for medium and low power laser processing users. We combine R&D, produce and sales in vertical integration in laser value chain.
Based on the quality control system, the whole series of regular types has been certificated by European CE certification.
We promise we will provide products of better quality and our best service!
Exhibition in whole world
We have participated in many international exhibitions:
D.PES SIGN EXPO CHINA (GUANGZHOU)
International Textile &Clothing Industry Fair (DOGNGUAN),
International Footwear&MaterialIndustry Fair (DOGNGUAN),
International Advertising & Exhibition (Shanghai)
Munich Exposition in Germany, etc.
If you are distributor, Aotopto laserhopes to cooperate with you and participate in your local fair to help you to open and occupy the market.
Certification of Aotopto Machine (CE,FDA)
Aotopto laser machine have passed testing and comply with the international standard. With CE, our machines own a good market in Europe. There is no problem to export machine to America with FDA.
If you want import machine to Egypt or some countries with strict regulation, we can provide fumigation certificate.
Q: How to choose among different models?
A: AZ/AZ-D Series: Sliding rail config. are mainly used for textile industry like fabric,textile,paper with faster speed
AZ-L Series: Square rail config.are mainly used for advertisement with higher precision for thick materials like acrylic, wood.
AZ-U Series: Up&down or rotary device is equipped for thick or cylindrical object on the base of standard series
AZ-H Series: Upgraded from D/L series, it’s equipped with square rail but larger working area
AZ-FH Series: On the base of AZ/AZ-D or H series, it’s suitable for both metal and non-metal.
Q: How about the package?
A: The machine will be wrapped with waterproof film and foam. We use strong seaworthy wooden box with fumigation to guaranty safe delivery.
Q: How about the delivery?
A: We have enough machines in stock. Exact delivery date is confirmed by actual order.
Q: Are you a factory or a trade company?
A: Yes, We are a factory.
Q: Where is your factory located? How can I visit there?
A: Our factory is located in Dongguan city, Guangdong province, China.
All our clients from home or abroad are warmly welcome to visit us!
Q: Do you have any certificates?
A: All series of machines have passed CE verification.
Q: What is the trade term?
A: FOB/CNF/CFR/CIF/EXW are favorable.
Q: What is the payment term?
A: We take 30% deposit and 70% balance should be paid before delivery by T/T.
West Union and PayPal are preferred for small amount.
Q: How can I get the documents after shipment?
A: All original documents will be sent to the client by DHL after shipping, including packing list, commercial invoice, B/L, and other certificates as required.
Q: Do you arrange shipment for the machines?
A: We will arrange shipment for transactions based on FOB/CIF terms.
For EXW price, shipment should be made by clients or their agents.
Any other questions will be replied as we receive your consult.
