5V 85mA Mini Epoxy Solar Panels

5V 85mA Mini Epoxy Solar Panels photo-1
US$ 0.3 - 2.5 MOQ: 5000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NZX
Model Number:
NZX-0.425W/5V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name NZX
Model Number NZX-0.425W/5V
Material Monocrystalline Silicon
Size 128mm*31mm
Number of Cells 10pcs
Max. Power 0.425W

Specifications

Mini Epoxy Solar Panels
1) Cell type: Monocrystalline
2)With CE,RoHS,ISO approval
3)High quality,low price,long lifespan

5V 85mA  Mini Epoxy Solar Panels



5V 85mA Mini Epoxy Solar Panels

Characteristics



Storage Battery

Solar Panel

1.2V

2~2.5V

2.4V

3.5~4V

3.6V

5~6V

6V

7.5~9V

12V

15~18V

Note:
1. When the voltage of your solar panel doesn't satisfy your storage battery, you can take

    two or more same solar panels together in series.
2. Such as, two 5.5V solar panel take together in series, so its voltage is 11V. When the

    voltage of solar panel satisfy your storage battery.
3. In order to speed up the rate of charge, you can take two or more solar panel together

    parallel connection.

Applications:

1. Small home projects
2. Science projects
3. Electronic applications
4. Charging small DC batteries
5. Build your DIY powered models/ solar toys/ solar displays









Max-power voltage VMP

5V

Max-power current IMP

85mA

Open-circuit voltage Voc

6V

Short-circuit current Isc

93mA

Max power PM

0.425W

Weight

30g

STC

Irradiance 1000W/m², temperature 25°c, AM=1.5

Sealed Tech

Epoxy resin





We can customize mini solar panel with different types and specifications, including mono or poly-crystalline or amorphous silicon, sealed technologies as encapsulated with epoxy resin, and PET or tempered glass laminating, various sizes.
