Help Center45W Mono Solar Panel
Negotiable
MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NZX
Material:
Monocrystalline Silicon
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
75W Mono/poly Silicon PV Solar Panel/Module for Home System UseUS$ 1.3 - 1.8MOQ: 10 Pieces -
PV Solar Panel/Polycrystaline Module-215WUS$ 1.6 - 1.7MOQ: 10 Pieces
-
85W Monocrystalline Solar ModulesUS$ 1.6 - 1.7MOQ: 50 Pieces
-
18V 130W Solar ModuleNegotiableMOQ: 100 Pieces
-
60W Solar Panels MonoUS$ 102 - 108MOQ: 50 Pieces
Place of Origin
Guangdong, China
Brand Name
NZX
Material
Monocrystalline Silicon
Size
670*530*30mm
Number of Cells
36pcs
Max. Power
45w
Specifications
45W Mono Solar Panel1,Certification:CE ,ISO 9000,ROHS
2,Power:45W/18V
4,With reasonable price directly from factory
45W Mono Solar Panel
Specifications
| ITEM NO.: | SPM-45W |
| Solar Cell: | 156*156(mm) mono |
| Maximum Power(W) | 45 |
| Optimum Power Voltage(Vmp) | 18 |
| Optimum Operating Current(Imp) | 2.54 |
| Open Circuit Voltage(Voc) | 22.3 |
| Short Circuit Current(Isc) | 2.75 |
| Nmber of Cell(pcs) | 4*9 |
| Size of Module(mm) | 670*530*30mm |
| Packing Configuration | 2PCS/CTN |
| Front Glass Thikness(mm) | 3.2 |
| Maxium System Voltage (V) | 700 |
| Maxium Series Fuse Rating(A) | 8 |
| Juction Box | lp54 rated |
| Noct | 48°C±2°C |
| Current Temperature Coefficient | 0.06±0.01%/K |
| Voltage Temperature Coefficient | -(78±10)MV/K |
| Power Temperature Coefficient | -(0.5±0.05)%/K |
| Temperature Range | -40°C to +85°C |
| Tolerance Wattage(e.g.+/-5%) | ±5% |
| Surface Maximum Load Capacity | 2400Pa |
| Allowable Hail Load | 23m/s ,7.53g |
| Weight Per Piece(KG) | 3.5 |
| Cell Efficiency | >17% |
| Frame(Material Corners,etc.) | Anodized Aluminum Alloy |
| Backing (Brand Type) | TPT |
| Warranty | 3 years for the whole product, for the power,90% for 10 years, 80% for 25 years |
| Standard Test Conditions | AM1.5 1000W/ 25 +/-2°C |
| FF (%) | 78% |
