Price for 90W Mono Solar Panels 12V

US$ 0.5 - 0.6 MOQ: 900 Watts

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

OEM

Model Number:

NZX-M90W 2

Shenzhen Ningzexin Solar Electricity Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shenzhen China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name OEM

Model Number NZX-M90W 2

Material Monocrystalline Silicon

Size 1196x534x35mm

Number of Cells 36pcs

Max. Power 90w

Price for 90W Mono Solar Panels

Specifications

ITEM NO.:	NZX-M90W 2
Solar Cell:	125*125(mm) mono
Maximum Power(W)	90
Optimum Power Voltage(Vmp)	17.4
Optimum Operating Current(Imp)	5.17
Open Circuit Voltage(Voc)	21.6
Short Circuit Current(Isc)	5.69
Nmber of Cell(pcs)	4*9
Size of Module(mm)	1196x534x35mm
Packing Configuration	2PCS/CTN or 1 PCS/CTN
Front Glass Thikness(mm)	3.2
Maxium System Voltage (V)	1000
Maxium Series Fuse Rating(A)	12
Juction Box	lp65 rated
Noct	48°C±2°C
Current Temperature Coefficient	0.06±0.01%/K
Voltage Temperature Coefficient	-(78±10)MV/K
Power Temperature Coefficient	-(0.5±0.05)%/K
Temperature Range	-40°C to +85°C
Tolerance Wattage(e.g.+/-5%)	±5%
Surface Maximum Load Capacity	2400Pa
Allowable Hail Load	23m/s ,7.53g
Weight Per Piece(KG)	8.5
Cell Efficiency	>17%
Frame(Material Corners,etc.)	Anodized Aluminum Alloy
Backing (Brand Type)	TPT
Warranty	3 years for the whole product, for the power,90% for 10 years, 80% for 25 years
Standard Test Conditions	AM1.5 1000W/ 25 +/-2°C
FF (%)	78%
