Help Center60W Solar Panel
US$ 0.85 - 1.2
MOQ: 100 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
NZX
Model Number:
NZX-60WM18V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
China Factory 100W Mono Crystalline Silicon Solar ModuleUS$ 0.8 - 0.85MOQ: 300 Pieces -
170W Solar Panel With Mono Crystalline CellUS$ 0.8 - 1.2MOQ: 100 Pieces
-
120W Mono Crystalline Solar PanelsUS$ 192.5 - 216.8MOQ: 50 Pieces
-
215W Monocrystalline Solar PanelUS$ 448.5 - 503.95MOQ: 20 Pieces
-
18v Solar Panel, Small Solar Panel 5w 18v ( Customize Different Model Solar Panels )NegotiableMOQ: 500 Pieces
Place of Origin
Guangdong, China
Brand Name
NZX
Model Number
NZX-60WM18V
Material
Monocrystalline Silicon
Size
899*537*35mm
Number of Cells
36PCS
Max. Power
60W
Specifications
Solar panel1,Certification: CE ,TUV,ISO 9000,ROHS2,steady photovoltaic
3,High efficiency:17%
60W MONO Solar panel
Certification:CE ,TUV,ISO 9000,ROHS
2,steady photovoltaic
3,High efficiency:17%
| ITEM NO.: | NZX-60WM18V |
| Solar Cell: | 125*93.75 Mono |
| Maximum Power(W) | 60w |
| Optimum Power Voltage(Vmp) | 17 |
| Optimum Operatige Current(Imp) | 3.53 |
| Open Circuit Voltage(Voc) | 21.5 |
| Short Circuit Current(Isc) | 3.84 |
| Nmber of Cell(pcs) | 4*9 |
| Size of Module(mm) | 899*537*35mm |
| Front Glass Thikness(mm) | 3.2 |
| Maxium System Voltage (V) | 1000 |
| Temperature Coefficients of Isc(%) | 0.065+/-0.015% |
| Temperature Coefficients of Voc(%) | -2.23+/-0.1 |
| Temperature Coefficients of Pm(%) | -0.5+-0.05 |
| Temperature Coefficients of Im(%) | +0.10 |
| Temperature Coefficients of Vm(%) | -0.38 |
| Temperature Range | -40°C to +85°C |
| Tolerance Wattage(e.g.+/-5%) | ±5% |
| Surface Maximum Load Capacity | 2400Pa |
| Allowable Hail Load | 23m/s ,7.53g |
| Weight Per Piece(KG) | 5.9 |
| Cell Efficiency for 180W(%) | >17% |
| Frame(Material Corners,etc.) | Anodized Aluminum Alloy |
| Backing (Brand Type) | TPT |
| Warranty | 3 years for the whole product, for the power,90% for 10 years, 80% for 25 years |
| Standard Test Conditions | AM1.5 1000W/ 25 +/-2°C |
| FF (%) | 73% |
