High Efficiency Multi-function Screw Conveyor for Sale
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
Type:
Screw Conveyor
Material:
Stainless Steel
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai Tianjin Qingdao etc
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Stainless Steel Grain Augers for SaleNegotiableMOQ: 1 Set -
HIgh Capacity Muliti-function Grain Augers for SaleNegotiableMOQ: 1 Set
-
No Leakage Reliable Small Grain Augers for SaleNegotiableMOQ: 1 Set
-
Reasonable Structural Design Screw Conveyor China for Concrete UsedNegotiableMOQ: 1 Set
-
Flexible Stainless Steel Screw Conveyor for PowderNegotiableMOQ: 1 Set
Condition
New
Type
Screw Conveyor
Material
Stainless Steel
Material Feature
Heat Resistant
Structure
Other, Srew Conveyor
Load Capacity
25-75 t/h
Place of Origin
Henan, China
Brand Name
Huaning Screw Conveyor
Model Number
LSY Series
Voltage
220V, 380V, or customized
Power(W)
5.5-18.5kw
Dimension(L*W*H)
Vary according to differeernt models
Certification
ISO, CE
After-sales Service Provided
No overseas service provided
High Efficiency Multi-function Screw Conveyor for sale
Brief Introduction of High Efficiency Multi-function Screw Conveyor for sale
- Multi-function Screw Conveyor is a new delivery device, pushing the materials continuous by the spiral rotary blades in the closed housing of circular cross-section. It's ideal for transporting kinds of bulk powser and particles, such as cement, fly ash, sand, stone powder, grain, etc. But this machine is not suitable for materials featured by large viscidity, caking or perishable.
- It is particularly suitable for the cement transmission from cement silos to concrete mixer.The working angle is generally between 0-45degrees.
Features of High Efficiency Multi-function Screw Conveyor for sale
- It is featured with compact structure, small cross-sectional area, lightweight, good sealing, high efficiency, ssafe operation, flexible process layout, installation, demotion, etc.
Main Technical Parameters of High Efficiency Multi-function Screw Conveyor for sale
Model |
LSY165 |
LSY219 |
LSY273 |
LSY325 |
Shell Diameter(mm) |
165 |
219 |
273 |
325 |
Screw Diameter(mm) |
135 |
189 |
243 |
295 |
Conveying Length(m) |
2-12 |
2-12 |
2-12 |
2-12 |
Rotation Speed (r/min) |
300 |
200 |
209 |
174 |
Working Angle |
0-45 |
0-45 |
0-45 |
0-45 |
Conveying Capacity (t/h) |
25 |
35 |
50 |
75 |
Motor Type |
Y100L-4 |
Y132M-4 |
Y160M-4 |
Y180M-4 |
Motor Power (kw) |
5.5-7.5 |
5.5-11 |
7.5-15 |
7.5-18.5 |
Our Services
Company Information
- Henan Huaning Machinery & Equipment Co., Ltd is one of the large-scale enterprises of construction machinery. It is specialized in manufacturing and selling concrete equipment for more than 20 years. Up to now, we already have 14 experienced engineers and 180 staffs.
- All our products have passed ISO9001 International Quality System Certification and high product quality wins the trust from most customers.
- Our main products are: Concrete Mixing Plant (HZS25, HZS35, HZS50, HZS60, HZS75, HZS90, HZS120, HZS180); Concrete Mixer (JS Series, JDC Series, JZC Series, JZM Series, JW Pan Concrete Mixer, Diesel Engine Concrete Mixer); Concrete Batching Machine; Screw Conveyor; Cement Silo; JZ350 Mortar Mixer; etc.
