ZING EAR Quick Connect Terminal 16A Micro Timer Switches 125V (UL/CUL/ENEC/RoHS/Reach Approval)
US$ 0.01 - 1.99
MOQ: 1000 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
ZING EAR
Model Number:
G5T16-E1P200
Payment & Shipping
Payment Methods:
Port of Shipment:
HK Shenzhen Guangzhou
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Micro Switch 15a, 16a 250v Micro Switch, UL, CUL, ENEC, CQC ApprovedUS$ 0.01 - 1MOQ: 1200 Pieces -
Push Button Micro Switch Led, Types of Micro Switch, Approved UL,CUL,ENEC,CQC,ROHS,Reach.US$ 0.1 - 0.669MOQ: 1000 Pieces
-
SPST-NC,15gOF, Global Safety Approvals Micro SwitchUS$ 0.2 - 0.5MOQ: 1200 Pieces
-
Micro SwitchESUS$ 0.2 - 0.5MOQ: 1200 Pieces
-
250v Home Electrical Power Tool SwitchUS$ 0.11 - 2.55MOQ: 5000 Pieces
Place of Origin
Guangdong, China
Brand Name
ZING EAR
Model Number
G5T16-E1P200
Max. Current
16A
Max. Voltage
250VAC
Operating Temperature
-25℃~125℃
Protection Level
IP00
ZING EAR Quick Connect Terminal 16A Micro Timer Switches 125V :
1. Our advantages:
uMore than 2,000 models of switch types.
uMonthly production capacity: 80 million pieces.
uOffer free samples for testing and physical approval.
uVarious types of operation force, operating lever, terminals for your choice.
uAutomatic assembly lines for entire production.
uGlobal safety approvals ENEC/CQC/UL/CUL, with certificates of ISO9001 & TS16949.
uImport Raw Materials with factory price.
uMore order quantities, more discounts!
u Long Life and High Reliability.
2. Parameters:
| Operating speed | 0.1mm-1m/s( Related with actuator forms) | |
| Operating frequency | Mechanical 60 cycles/min; Electrical 15 cycles/min. | |
| Insulation resistance | ≥100MΩ (500VDC) | |
| Contact resistance | ≤100MΩ (Initial value) | |
|
Test Voltage |
Between each terminals of the same polarity | AC1000V,50/60HZ, 1min. |
| Between current-carrying metal part and ground.and between each terminal and non-current-carring metal parts | AC1500V, 50/60HZ, 1min. | |
| Vibration resistance | 10-55HZ, 1.5mm Double amplitude | |
| Shock resistance | Destruction: OF>0.5N:1000m/s2 (approx.100G)max. | |
| Destruction:OF>0.5N:200m/s2 (approx.20G)max. | ||
| Life expectancy | Mechanical ≥ 10,000,000cycles or 1,000,000cycles | |
| Electrical ≥ 50,000cycles or 100,000cycles | ||
| Weight | Approx. 6.2g(No lever). | |
3.Plant and Certificates:
