Plastic PP Drinking Straw Making Machine
Illustration of Plastic PP Drinking Straw Making Machine
DNYL series high speed drinking straw extrusion plant is our new design in 2010.
We have adopted the screw diameter 50mm instead of the screw diameter 45mm,and L:D is 28:1.
The new design will more easy to plasticize and increase the production capacity.It is an economic and perfect machine for producing the straw.
Characteristics of Plastic PP Drinking Straw Making Machine
Colours: Single,two, three or five, spiral stripes, straight stripes.
Cut-end:90°/90°,90°/45°,90°/60°,45°/45°,60°/60°
All the direct contact parts made from stainless steel.
The cutting unit adopted the big plate cutter and with automatic gathering system.
The breaker ,AC contactor and knob switch brand is SCHNEIDER, The inverter brand is DELTA
Main Technical Data
Colour |
Single |
Two |
Three |
Diameter of screw: |
50mm |
50mm+1x25mm |
50mm+2x25mm |
L:D |
28:1 |
28:1 / 20:1 |
28:1 / 20:1/20:1 |
Max. extrusion capacity |
35kgs/h |
||
Material |
PE / PP |
||
Specification of straw |
Diameter.:φ2- φ 14mm |
||
Length tolerance:± 0.1 -1mm | |||
Thickness:0.05-1mm | |||
Capacity |
30000-60000pcs/h |
||
Power of extruder |
11kw,380v,50hz |
11kw+0.75kw,380v,50hz |
11kw+2x0.75kw,380v,50hz |
Power of hauling machine |
0.75kw,380v,50hz |
||
Power of cutter |
0.75kw,380v,50hz |
||
Power of gathering system |
0.18kw,380v,50hz |
||
Temperature controlling |
5 sections |
8 sections |
11 sections |
Standard Seaworthy Export Packing Plastic PP Drinking Straw Making Machine
a. Engineers available to service machinery overseas
b. Guarantee Period: 12 Months
c. During this guarantee period,TECHNO will provide spare parts without any charge in case of quality disrepancy caused by us.If the malfunction are caused by your incorrect operations,TECHNO will provide the buyer spare parts at cost price.
Zhangjiagang Techno Machinery Co.,Ltd. is specialized in manufacturing and exporting different kinds of plastic extrusion and plastic recycling machinery.
Our main machines include the following: 1) plastic pipes production line 2) plastic profiles production line 3) plastic sheets production line 4) plastic pellets production line 5) plastic mixers 6) plastic pulverizer 7) tire recycling machinery ......
Term of Payment
a. L/C
b. T/T (30% as advance payment by T/T after signing contract, 70% of total will be paid by T/T before delivery)
