Pipe Tube Expander Machine
- 10 Set / Sets per Month
- Shanghai
- T/T
Product Details
Condition: | New | Product Type: | Plastic Pipe | Place of Origin: | Jiangsu, China |
Brand Name: | Techno | Model Number: | SGK | Voltage: | 220-480V |
Power(W): | 7-50KW | Dimension(L*W*H): | about 7500*1930*2100mm | Weight: | 1500-8000KG |
Certification: | CE | Warranty: | 12 Months | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Pipe Belling Machine
Pipe Tube Expander Machine
Illustration of Pipe Tube Expander Machine
Fully automatic pipe belling machine is suitable for the U-PVC belling. Shapingway adopts rising in the mould and increasing the barometric pressure out of the mould to make it stereotypic.
Model | SGK | |
Belling Scope | Φ16mm-Φ1000mm | |
Belling-type | R-type, Square-type and Smooth type | |
Pipe Length | 3m-8m | |
Use Voltage | AC 380V; 50Hz (Or according to customer's request) | |
Central Height | According to customer's request | |
Molding mode | R-type | With collapsible core |
Smooth type | Pushing mould directly into pipe | |
Cooling mode | Air-cooling or Water cooling |
Main Parameter of Pipe Tube Expander Machine
Model | Pipe Belling Scope | Total Power | G.W. | Overall Dimensions (mm) | Belling Type |
SGK75S | Φ16mm-Φ75mm | 7kw | 1500kg | 7460×1950×1900 | U type |
SGK110 | Φ20mm-Φ110mm | 7kw | 1300kg | 7460×1550×1900 | U or R type |
SGK160 | Φ40mm-Φ160mm | 18kw | 2300kg | 7000×1530×1963 | R-type Smooth-type |
SGK250 | Φ50mm-Φ250mm | 18kw | 2500kg | 7300×1730×1950 | R-type Smooth-type |
SGK315 | Φ110mmΦ315mm | 25kw | 2800kg | 7500×1930×2100 | R-type Smooth-type |
SGK400 | Φ160mm-Φ400mm | 25kw | 3000kg | 7900×2140×2125 | R-type Smooth-type |
SGK630 | Φ315mm-Φ630mm | 32kw | 3500kg | 8423×2970×2650 | R-type Smooth-type |
SGK1000 | Φ500mm-Φ1000mm | 50kw | 8000kg | 10000×4600×2570 | R-type Smooth-type |
Pipe Tube Expander Machine
Standard Export Seaworthy Packing Pipe Tube Expander Machine
a. Engineers available to service machinery overseas
b. Guarantee Period: 12 Months
c. During this guarantee period,TECHNO will provide spare parts without any charge in case of quality discrepancy caused by us. If the malfunctions are caused by your incorrect operations,TECHNO will provide the buyer spare parts at cost price.
Zhangjiagang Techno Machinery Co.,Ltd. is specialized in manufacturing and exporting different kinds of plastic extrusion and plastic recycling machinery.
Our main machines include the following: 1)plastic pipes production line 2)plastic profiles production line 3)plastic sheets production line 4)plastic pellets production line 5)plastic mixers 6)plastic pulverizer 7)tire recycling machinery ...........
Term of Payment
a. L/C
b. T/T (30% as advance payment by T/T after signing contract, 70% of total will be paid by T/T before delivery)
