15" Capacitive touch screen CCTV LCD monitor Quality Choice
USD $1 - $109
/ Piece
1 Piece(Min.Order)
- 3000 Piece / Pieces per Month
- Shenzhen
- Credit Card
You May Like
Product Details
| Products Status | Stock | Application | Other, customized | |
| Screen Size | Other, 15" | Response Time | 10ms | |
| Brightness | 500cd/m | Interface Type | D-Sub, HDMI, RS232C, YPBPR | |
| Contrast Ratio | Other, 1200:1 | Resolution | 1024 x 768 | |
| Widescreen | Yes | Panel Type | TFT | |
| Pixel Pitch | 0.297*0.297 | Brand Name | USER(or OEM) | |
| Model Number | US-T1501C | Place of Origin | Guangdong, China |
Product Description
15" touch screen LCD monitor
Product Description
Product Description for 15" Capacitive touch screen CCTV LCD monitor
| Features: | ||
| 1.Apply excellent quality infrared touch screen panel, super high transmittance, high anti-violence ability, resist scratch and mill, dust-proof and waterproof 2.High touch sensitivity, response quick, no drift 3.Professional chip and process technology, ensure high quality image 4.Industrial grade and high performance LCD panel, ensure image high definition, high brightness and dependable performance; 5.The case apply high strengthen steel design, appearance ultrathin, delicate and compact, have excellent performance in prevention grade and electromagnetic shielding; 6.In the farce, paint fine lines, smooth and uniform, integrate the color with the industrial host, have excellent anti-dust and resist-mill 7.Support multi-signals interfaces, also many signals inputs / outputs; 8.High reliability,high stability, suit to education and train, exhibition, public media, video meeting, force guarding, traffic management etc. | ||
| Specification | ||
| LCD Panel | Model No. | US-T1501C |
| Panel Size | 15” TFT-LCD | |
| Display area | 304(W)×228(H) | |
| Max Resolution Support | 1024×768 | |
| Color | 16.7M | |
| Brightness (nits) | 500cd/m2 | |
| Contrast | 1200:1 | |
| Visual Angle (H/V) | H160º V160º | |
| Response Time | 8ms | |
| Life(hrs) | ≥60000 | |
| Touch panel | Specification | Capacitive touch |
| light transmittance | 80%-90% | |
| Hardness | 7H | |
| Click way | Single point | |
| Response Time | 10ms | |
| Output resolution | 4096×4096 | |
| Life span | more than 500W times | |
| Input and output | Composite video input | 2(BNC×2) |
| Composite video loop out | 1(BNC×1) | |
| D-15Pin RGB Input | 1 | |
| HDMI | 1 | |
| S-video | No | |
| YPbPr | 1(BNC×3) | |
| Video | Color system | PAL/NTSC/SECAM |
| OSD display | Language menu | Chinese/English (Other Optional) |
| Power | Input voltage | DC 12V 2.6A |
| Max Power consumption | ≤25W | |
| Standby power consumption | ≤3W | |
| Appearance | Body dimension(Lx W x H)mm | 329*258*60 |
| Panel color | White/Black (customized) | |
| Case Material | Metal(SPCC) | |
| Installation | Wall mount,Bottom case | |
| Work environment | Working temperature | 0°C~50°C |
| Storage temperature | -10°C~60°C | |
| Working humidity | 20%~80% | |
| Storage humidity | 5~95% | |
| Other | Certificate | CE/FCC/3C/RoHS |
| Accessory | Instruction,Warranty card,Certificate of quality,Remote control,data line3.0M,Power cable1.8M | |
