Specifications
12.1" touch screen LCD monitorHigh performance and moderate in price
Delivery timely
Full service
12.1" touch screen LCD monitor
Multi-function Touch screen LCD Monitors
with built-in Speakers, Remote Control and Wall Mountable Stand
This monitor can be used as:
A great POS Touch Screen
A great Touch Screen PC Monitor
A great Portable TV for replay Video in RV, Car, Boat etc.
This new 12” touchscreen monitor is perfect for use in retail, point-of-sale (POS), VOD system, Juke Box and many other hospitality applications. Easily integrated with a variety of POS, thin client or PC systems, the touch LCD features 4-wire resistive touchscreen and USB touchscreen interface. The touchscreen monitor comes with a multi-function stand. It is also compatible with wall mounting options through two holes on stand. The sensitive touch screen recognizes touch input from stylus, finger, gloved hand, pen or tool .It's an exceptional durable touchscreen monitor and an excellent value.
Features
Adopt industrial LCD screen, high native resolution of 800*600, High contrast and brightness, wide viewing angle, which greatly improve the image layering.
One of the world's most high-precision four wires resistive type touch-screen for PC display.
(USB port/COM RS232 optional)
Sensitive touch-screen, quick response
Standard VGA (15 pin D-SUB RGB) and Two RCA/BNC video input
Built-in speaker amplifier/PC audio input and earphone jack
Operating All Systems: DOS/Windows 9X ME 2K XP 7 Vista NT CE / LINUX / Mac,etc.
Can support almost all kinds of resolution
Low radiation and consumption. High reliability, good stability, especially for work in harsh environments.
Specification
*Model: YT121
*Description: 12.1″ TFT Touch Monitor
*Case/Bezel Colour: Black/silver
*Touch monitor Performance: Standard
*Display Type: 4:3 Ratio12.1″Active Matrix TFT LCD
*Native Resolution :800 x 600 @ 60Hz _1024 x 768 @ 75Hz
*Sychronization Range: 30-80 KHz horizontal, 55-75 Hz Vertical
*Pixel Pitch: 0.297(W) X 0.24(H) mm
*Pixel Response Time Rise + Fall (Typically): 12ms
*Plug and Play: VESA DDC 1/2B
*On Screen Display (OSD): Remote OSD
*Colours: 16.7 million
*Brightness: 400 cd/m2
*Contrast Ratio Typically: 400:1
*Viewing Angle Horizontal (left/right): 170° (85°/85°)
* (From Centre, CR>=5) Vertical (up/down): 160° (70°/90°)
*Backlight Lamp life Hrs to 1/2 brightness: 50,000
*Input Video Format: Analog RGB , CVBS NTSC/PAL (AUTO)
*Touch screen Interface: Serial (RS232) or USB
*Touch Response Time Serial/USB: 10.4ms
*Touch Sensitivity: Fixed
*Touch Pen Hitting Life: >= 1milions times
*Monitor Dimensions: 313x229x44(mm)
*Shipping Carton Dimensions:347x299x115(mm)
*Provider Weight (approximately) Monitor/Shipping: 2.7kg
*Power Supply: External: 85-265VAC, 50-60 Hz
*Power Consumption: <20 W Typ
*Temperature Range: Operating:0°C-50°C, Storage:-20°C-80°C
*Relative Humidity Non Condensing: Operating:10%-90%,
Storage 5%-90%
*Warranty: 1 year
*Agency Approvals: FCC, CE, ROHS
Accessories
VGA cable
Touch USB cable
Video/audio cable
BNC cable (optional)
Remote
Power Supply Adaptor
Power Lead(US,EU ,UK etc type)
Software touch driver CD
User Manual (English)
Touch Pen
Bracket
Typical Applications
Entertainment /Casino Systems
Outdoor and indoor Kiosks
Entertainment
Transport and Ticketing
Television station
Education
Exhibition
Advertisement
Hotel/Hospitality
Car PC
Industry equipment
Banking
Customised Solutions
