Home > Consumer Electronics > Display & Accessories > Touch Screen > Iphone Design Lcd Touch Monitor Screen With Android System
Iphone Design Lcd Touch Monitor Screen With Android System
US$ 10 - 200
MOQ: 1 Piece
Key Specifications
Get Latest Price
Products Status:
Stock
Screen Size:
Other, 42"
Type:
Infrared
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Usb Powered Touch Screen,wall Mount 42 Inch Touch ScreenUS$ 10 - 200MOQ: 1 Piece -
Multi Points Touch Monitor Screen 46 InchUS$ 10 - 200MOQ: 1 Piece
-
6 Points Touch Monitor 46 InchUS$ 10 - 200MOQ: 1 Piece
-
46 Inch Touch Screen With Nice Iphone DesignUS$ 10 - 200MOQ: 1 Piece
-
Wall Mount Multi Touch Led Monitor 46 InchUS$ 10 - 200MOQ: 1 Piece
Products Status
Stock
Screen Size
Other, 42"
Type
Infrared
Interface Type
Serial, USB, Other, Serial, USB, HDMI,Composite video input and output
Resolution
Other, 1920*1080
Brand Name
User(or OEM)
Model Number
US-T4201HC-A
Place of Origin
Guangdong, China
Specifications
Android systemHigh definition and brightness
Good in quality and moderate in price
Delivery timely
Warranty One Year
Iphone design lcd touch monitor screen with Android system
| Specifications | ||||||||||
| Model No. | US-T4201HC-A | |||||||||
| Panel size | 42" TFT-LCD | |||||||||
| Display area(mm)/mode | 930(W)×523.0(H) 16:9 | |||||||||
| Maximum resolution | 1920×1080 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.4845(H)×0.4845(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 1400:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 50-70KHZ | |||||||||
| Backlight mode | LED | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Specifications for touch screen | ||||||||||
| Panel size | 26"~65" | |||||||||
| Maximum resolution | 4096*4096 | |||||||||
| Linearity error | <5MM | |||||||||
| Scanning speed | 50SCANS/S | |||||||||
| Durability | stand more than 60000000 times multi-points touch | |||||||||
| Surface hardness | 7H | |||||||||
| Transmittance | ≥98% | |||||||||
| Response time | <16MS | |||||||||
| System support | Android , WIN7/XP | |||||||||
| Input and output | ||||||||||
| SD | 1 (support 1080P, up to 32G) | |||||||||
| SATA hard disk | support | |||||||||
| Network infterface | RJ45 10/100M Network Adaptive | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| USB | Support USB 2.0, support FAT,FAT32,exFAT and NTFS format | |||||||||
| LVDS interface | can drive lcd screen directly | |||||||||
| Video and audio | ||||||||||
| Video system | PAL/NTSC/SECAM | |||||||||
| Play formats | Compatible many play formats | |||||||||
| Video | H.264,MKV,WMV9,MPEG 1/2/4,HD Divx,Xvid,RM/RMVB | |||||||||
| Audio | MP3,WMA,WAV,EAAC+, MP2 dec, Vorbis(Ogg), AC3, FLAC, APE, BSAC | |||||||||
| Picture | BMP/PNG/GIF/JPEG(4088*4088) | |||||||||
| Word | TXT | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <=280W | |||||||||
| Standby power consumption | <=3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -10°C~60°C | |||||||||
| Working humidity | 20%~80% | |||||||||
| Storage humidity | 5%~95% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 1249.6×739.2×122.2((for reference only) | |||||||||
| Panel color/appearance | Ipad design | |||||||||
| Panel material | SPCC/Aluminum/Customized | |||||||||
| Installation | wall mount | |||||||||
| Certificate | CE/FCC/3C/RoHS | |||||||||
