8" CCTV LCD Monitor with BNC interface
Product NO.: US-M0801P
Screen: 8"TFT-LCD
Display area: 166(W) x 125.5(H) (mm)
Resolution: 800 x 600
Aspect Ratio: 4:3
Contrast Ratio : 300:1
Number of Colors : 16.7M
Brightness : 300cd/m2
Viewing Angle : 140°/150°
Pixel Pitch : 0.264(H) x 0.264(V) (mm)
Response Time (GTG) : 5ms (Typical)
Horizontal frequency : 31-48KHZ
Vertical frequency : 56-60KHZ
Working temperature: 0~50degree
Storage temperature : -10~60degree
Surface Treatment : Anti-Glare
Color system : PAL/NTSC/SECAM
Composite video input : 1(BNC×1)
Y Pb Pr/Y Cb Cr input : optional
D-15 pin RGB input : 1
Language : Chinese, English, espanol, Italiano, Francais, Deutsch
Color : black (customized)
Dimension : 189.6L×148.7W×43D (mm)
Installation : wall-mounted, desktop
Life : no less than 60,000 hours
Voltage : DC12V/2.6A
On Mode (Average): 15W (Max)
Standby Mode : <1W (Max)
Standard export package (with PE bag and foam,2pcs in a carton,wooden frame)
1.Reply your inquiry in 24 working hours.
2.Experienced staffs answer all your questions in fluent English.
3.Customized desgin is avaliable,OEM&ODM is welcomed.
4.Suitable solution can be provided to our customer by our professional engineers and staffs.
We are the most professional electronic security production manufacturer in China.
We could provide best solutions for every customer according to different products and culture.
Our company spirit: Be responsible to every customer, Be responsible ourselves.
How to order?
1.Tell us what model and quality you need,Get Latest Quote.
2.Confirm order details,Reach Trading Intention,We will send the PI.
3.Tell us shipping address and contact telephone No,Arrange the payment.
4.After confirm the payment,we will ship out the order in 7 working days (Sample order).
Contact info:
Mobile: +86-18923749870 or +86-13113616594
Skype:joy.deng69
Whatsapp: +86-13113616594
