22 Inch Cctv Lcd Monitor With Matal Case
- Shenzhen
- T/T Credit Card PayPal
You May Like
Product Details
| Place of Origin | Guangdong, China | Brand Name | USER | |
| Model Number | US-M2201P |
Product Description
Specifications
1. 22'' TFT lcd panel2. 1680*1050 16:10
3. 450nits 1000:1
4. wide visual angle, up to 178D
5. HDMI, VGA, CVBS, VGA, YUV
Product name: 22 inch cctv lcd monitor with matal case
Specification model | US-M2201P |
| |||||
Panel size | 22″TFT-LCD |
| |||||
Display area(mm)/mode | 476(W)×298(H) 16:10 |
| |||||
Maximum resolution | 1680×1050 |
| |||||
Display color | 16.7M |
| |||||
Pixel Pitch(mm) | 0.282(H)×0.282(V) |
| |||||
Brightness (nits) | 450cd/m2 |
| |||||
Contrast | 1000:1 |
| |||||
Visual angle | 178°/178° |
| |||||
Response time | 5ms |
| |||||
Horizontal frequency | 30-75KHZ |
| |||||
Vertical frequency | 56-75KHZ |
| |||||
Life(hrs) | >60,000(hrs) |
| |||||
Input and output |
|
| |||||
Composite video input | 2 (BNC×2) |
| |||||
Y,Pb,Pr/Y,Cb,Cr input | 3 (BNC×3) |
| |||||
S-video | 1 (optional) |
| |||||
D-15 pin RGB input | 1 |
| |||||
DVI/HDMI | 1 (optional) |
| |||||
Composite video output | 1 (BNC×1) |
| |||||
Video |
|
| |||||
Color system | PAL/NTSC/SECAM |
| |||||
Compatible HDMI input/DVI | 480P,576P,720P,1080I,1080P |
| |||||
3D Comb filter | Yes |
| |||||
Video reduction noise | Yes |
| |||||
OSD display( screen menu display) |
|
| |||||
Menu language | Chinese/English( multiple language option required) |
| |||||
Power |
|
| |||||
Power supply | AC100V~240V,50/60Hz |
| |||||
Maximum power consumption | 52W |
| |||||
Standby power consumption | 3W |
| |||||
Temperature |
|
| |||||
Working temperature | 0°C~50°C |
| |||||
Storage temperature | -20°C~60°C |
| |||||
Working humidity |
|
| 60% |
|
|
| |
Storage humidity |
|
| 60% |
|
|
| |
Appearance |
|
| |||||
Body dimension(Lx W x H)mm | 496.7×323.1×66 |
| |||||
Panel color/appearance | White, black, customized |
| |||||
Panel material | metal |
| |||||
Net weight | 10kg |
| |||||
Installation | wall-mounted, desktop (optional) |
| |||||
