Help CenterSecurity Field 15" CCTV Monitor
Negotiable
MOQ: 5 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Resolution:
Other, 1024x768
Brightness:
Other, 350nits
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Resolution
Other, 1024x768
Brightness
Other, 350nits
Specifications
1. Security field 15" CCTV monitor2. CE, FCC,RoHS certified
3. BNC,VGA,HDMI,YPbPr input
4. Metal casing
5.Special for cctv
Security field 15 " CCTV Monitor
Specifications | ||||||||||
| Model No. | US-M1501P | |||||||||
| Panel size | 15" TFT-LCD | |||||||||
| Display area(mm)/mode | 306(W)×230(H) 4:3 | |||||||||
| Maximum resolution | 1024×768 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.297(H)×0.297(V) | |||||||||
| Brightness (nits) | 350cd/m2 | |||||||||
| Contrast | 800:1 | |||||||||
| Visual angle | 150°/160° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | 60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 2 (BNC×2) | |||||||||
| YPbPrinput | 1 (BNC×3) | |||||||||
| S-video | 1 (optional) | |||||||||
| VGA | 1 | |||||||||
| HDMI | 1 | |||||||||
| Composite video output | 1 (BNC×1) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | 25W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 10%-90% | |||||||||
| Storage humidity | 10%-90% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 329x258x57 | |||||||||
| Panel color/appearance | black,customized | |||||||||
| Case Material | Steel | |||||||||
| Net weight | 3.9kg | |||||||||
| Installation | Wall-mounted,desktop(optional) | |||||||||
