Security 24" CCTV LCD Monitor
Negotiable
/ Set
5 Sets(Min.Order)
- 2000 Set / Sets per Month
- Shenzhen
- T/T Credit Card
You May Like
Product Details
Resolution: | Other, 1920x1200 | Brightness: | Other, 500nits |
Product Description
Specifications
1. Security 24" CCTV LCD monitor2. CE, FCC,RoHS certified
3. BNC,VGA,HDMI,YPbPr input
4. Metal casing
5.For cctv monitoring
Security 24 " CCTV LCD Monitor
Specifications | ||||||||||
Model No. | US-M2401P | |||||||||
Panel size | 23.6" TFT-LCD | |||||||||
Display area(mm)/mode | 522(W)x294(H) 16:10 | |||||||||
Maximum resolution | 1920x1200 | |||||||||
Display color | 16.7M | |||||||||
Pixel Pitch(mm) | 0.270(H)×0.270(V) | |||||||||
Brightness (nits) | 500nits | |||||||||
Contrast | 1200:1 | |||||||||
Visual angle | 178°/178° | |||||||||
Response time | 5ms | |||||||||
Horizontal frequency | 31-60KHZ | |||||||||
Vertical frequency | 56-75KHZ | |||||||||
Life(hrs) | 60,000(hrs) | |||||||||
Input and output | ||||||||||
Composite video input | 3 (BNC×3) | |||||||||
YPbPr input | 1 (BNC×3) | |||||||||
S-video | 1(BNCx2) | |||||||||
VGA | 1 | |||||||||
DVI | 1 | |||||||||
HDMI | 1 | |||||||||
Composite video output | ||||||||||
Video | ||||||||||
Color system | PAL/NTSC/SECAM | |||||||||
Compatible HDMI/DVI input | 480P,576P,720P,1080I,1080P | |||||||||
3D Comb filter | Yes | |||||||||
Video reduction noise | Yes | |||||||||
OSD display( screen menu display) | ||||||||||
Menu language | Chinese/English | |||||||||
Power | ||||||||||
Power supply | AC100V~240V,50/60Hz | |||||||||
Maximum power consumption | 65W | |||||||||
Standby power consumption | 3W | |||||||||
Temperature | ||||||||||
Working temperature | 0°C~50°C | |||||||||
Storage temperature | -20°C~60°C | |||||||||
Working humidity | 10%-90% | |||||||||
Storage humidity | 10%-90% | |||||||||
Appearance | ||||||||||
Body dimension(Lx W x H)mm | 549.8mm*367mm*95mm | |||||||||
Panel color/appearance | White,black,customized | |||||||||
Case Material | Metal | |||||||||
Net weight | 10kg | |||||||||
Installation | Wall-mounted,desktop(optional) |
