Home > Security & Protection > Surveillance, Control & Protection > Monitor > Fhd 42" Lcd Cctv Monitor With 3 BNC Input
Fhd 42" Lcd Cctv Monitor With 3 BNC Input
Negotiable
MOQ: 3 Sets (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER
Model Number:
US-M4201P
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Professional 22" Security MonitorNegotiableMOQ: 15 Sets -
Professional 17" Security Lcd MonitorNegotiableMOQ: 30 Sets
-
CCTV Monitor 60 Inch With Remote ControlNegotiableMOQ: 1 Set
-
55 Inch CCTV Lcd Monitor (5~82")NegotiableMOQ: 1 Piece
-
47" Lcd CCTV Test Monitor With Best PriceNegotiableMOQ: 1 Set
Place of Origin
Guangdong, China
Brand Name
USER
Model Number
US-M4201P
Specifications
42" lcd cctv monitorBNC,VGA,HDMI,DVI,Ypbpr
Good quality with moderate price
CE,RoHS,FCC,UL
OEM/ODM/delivery in time
42" lcd cctv monitor with 3BNC input
| Specifications | ||||||||||
| Model No. | US-M4201P | |||||||||
| Panel size | 42" TFT-LCD | |||||||||
| Display area(mm)/mode | 930(W)×523.0(H) 16:9 | |||||||||
| Maximum resolution | 1920×1080 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.4845(H)×0.4845(V) | |||||||||
| Brightness (nits) | 600cd/m2 | |||||||||
| Contrast | 1000:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 3 (BNC×3) | |||||||||
| YPbPr input | 1 (BNC×3) | |||||||||
| S-video-Y/C input | 2 (BNCX2) | |||||||||
| VGA | 1 | |||||||||
| HDMI | 1 | |||||||||
| DVI | 1 | |||||||||
| Composite video output | 2 (BNC×2) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Compatible HDMI/DVI input | 480P,576P,720P,1080I,1080P | |||||||||
| 3D Comb filter | Yes | |||||||||
| Video reduction noise | Yes | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | 220W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 10%~90% | |||||||||
| Storage humidity | 10%~90% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 996.6×596.0×116.2mm | |||||||||
| Panel color/appearance | White,black,customized | |||||||||
| Case Material | Metal | |||||||||
| Net weight | 37kg | |||||||||
| Installation | Wall-mounted | |||||||||
