Home > Products > CCTV LCD Monitor(Professional) > professional 17" security lcd monitor
professional 17" security lcd monitor
Negotiable
/ Set
30 Sets(Min.Order)
- 2000 Set / Sets per Month
- Shenzhen
You May Like
Product Description
Specifications
17" security lcd monitorSpecial design for CCTV
Rice interface:BNC, VGA,HDMI,etc
Long life, good quality
CE,RoHS,FCC,
Professional 17" security lcd monitor
| Model No. | US-M1701P | |||||||||
| Panel size | 17" TFT-LCD | |||||||||
| Display area(mm)/mode | 340(W)×273(H) 4:3 | |||||||||
| Maximum resolution | 1280x1024 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.264(H)×0.264(V) | |||||||||
| Brightness (nits) | 450cd/m2 | |||||||||
| Contrast | 1000:1 | |||||||||
| Visual angle | 170°/170° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 2 (BNC×2) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | 3 (BNC×3) | |||||||||
| S-video | 1 (optional) | |||||||||
| VGA | 1 | |||||||||
| HDMI | 1 | |||||||||
| Composite video output | 1 (BNC×1) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <35W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 10%~75% | |||||||||
| Storage humidity | 85% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 361.0×300×66 | |||||||||
| Panel color/appearance | White,black,customized | |||||||||
| Case Material | Metal | |||||||||
| Net weight | 5.5kg | |||||||||
| Installation | Wall-mounted,desktop Optional | |||||||||
