Help Center32'' CCTV Monitor
Negotiable
MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
user
Model Number:
US-M3201P
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
22'' CCTV Monitor (professional/industrial/commercial Grade)US$ 1 - 5MOQ: 1 Piece -
20'' CCTV LCD Monitor(professional)NegotiableMOQ: 50 Pieces
-
15'' CCTV LCD Monitor(professional)NegotiableMOQ: 50 Pieces
-
8'' Car LCD MonitorNegotiableMOQ: 50 Pieces
-
52'' Professional LCD CCTV MonitorNegotiableMOQ: 20 Sets
Place of Origin
Guangdong, China
Brand Name
user
Model Number
US-M3201P
Specifications
astest anti-glare designSlim and lightweight design
High-contrast, high brightness
Professional CCTV monitor
CCTV monitor specification:
| Specification model | US-M3201P | |||||||||
| Panel size | 32″TFT-LCD | |||||||||
| Display area(mm)/mode | 700(W)×394(H) 16:9 | |||||||||
| Maximum resolution | 1366×768 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.51075(H)×0.51075(V) | |||||||||
| Brightness (nits) | 500cd/m2 | |||||||||
| Contrast | 1500:1 | |||||||||
| Visual angle | 178°/178° | |||||||||
| Response time | 8ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| Composite video input | 2 (BNC×2) | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | 1 (BNC×3) | |||||||||
| S-video | 1 | |||||||||
| D-15 pin RGB input | 1 | |||||||||
| DVI/HDMI | 1 (option) | |||||||||
| Composite video output | 2 (BNC×2) | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| Compatible HDMI input/DVI | 480P,576P,720P,1080I,1080P | |||||||||
| 3D Comb filter | Yes | |||||||||
| Video reduction noise | Yes | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( multiple language option required) | |||||||||
| Power | ||||||||||
| Power supply | AC100V~240V,50/60Hz | |||||||||
| Maximum power consumption | <=120W | |||||||||
| Standby power consumption | 3W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0~50 celsius | |||||||||
| Storage temperature | -20~60 celsius | |||||||||
| Working humidity | 80% | |||||||||
| Storage humidity | 60% | |||||||||
| Appearance | ||||||||||
| Body dimension(Lx W x H)mm | 773.6×470.0×116.2 | |||||||||
| Panel color/appearance | White, black, customized | |||||||||
| Panel material | metal | |||||||||
| Installation | Embedded, wall-mounted, rack-mounted, desktop | |||||||||
