10.4 Inch Cctv Lcd Desktop Monitor
US$ 50 - 500
MOQ: 4 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
USER
Model Number:
US-M1041P
Payment & Shipping
Payment Methods:
Port of Shipment:
FOB shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Place of Origin
Guangdong, China
Brand Name
USER
Model Number
US-M1041P
Specifications
1.10.4 inch cctv lcd desktop monitor2.CE FCC ROHS UL
3.HD A+ screen
4.long life span
5.warranty:1year
| Specifications | ||||||||||
| Model No. | US-M1041P | |||||||||
| Panel size | 10.4" TFT-LCD | |||||||||
| Display area(mm)/mode | 214(W)×160(H) 4:3 | |||||||||
| Maximum resolution | 800x600 | |||||||||
| Display color | 16.7M | |||||||||
| Pixel Pitch(mm) | 0.264(H)×0.264(V) | |||||||||
| Brightness (nits) | 350cd | |||||||||
| Contrast | 350:1 | |||||||||
| Visual angle | 140°/150° | |||||||||
| Response time | 5ms | |||||||||
| Horizontal frequency | 30-75KHZ | |||||||||
| Vertical frequency | 56-75KHZ | |||||||||
| Life(hrs) | >60,000(hrs) | |||||||||
| Input and output | ||||||||||
| VGA | 1 | |||||||||
| RGB input | 1 | |||||||||
| S-video input | Optional | |||||||||
| Y,Pb,Pr/Y,Cb,Cr input | Optional | |||||||||
| Composite video input | 1(BNC×1) | |||||||||
| Composite video output | Optional | |||||||||
| Video | ||||||||||
| Color system | PAL/NTSC/SECAM | |||||||||
| OSD display( screen menu display) | ||||||||||
| Menu language | Chinese/English( Multiple Language Supported) | |||||||||
| Power | ||||||||||
| Power supply | DC12V 2A | |||||||||
| Maximum power consumption | 18W | |||||||||
| Standby power consumption | <1W | |||||||||
| Temperature | ||||||||||
| Working temperature | 0°C~50°C | |||||||||
| Storage temperature | -20°C~60°C | |||||||||
| Working humidity | 40%-85% | |||||||||
| Storage humidity | 85% | |||||||||
10.4 inch cctv lcd desktop monitor
