Help CenterQC11K 16x8000mm CNC Shear Machine for Metal Sheet
Related Products
-
QC11Y 40x4000 Hydraulic Shearing Machine for Mild SteelUS$ 68,800 - 73,400MOQ: 1 Set -
QC11Y-20X6000 Steel Plate Shear for Door FrameUS$ 38,000 - 51,000MOQ: 1 Set
-
QC11YK 8X4000mm High Speed Hydraulic Pendulum Shearing MachineUS$ 17,500 - 18,200MOQ: 1 Set
-
QC11YK 8X4000mm Fast Hydraulic Pendulum Shearing MachineUS$ 17,500 - 38,200MOQ: 1 Set
-
QC11YK 8x6000 Fast Hydraulic Cutting Machine for Metal Sheet ShearingUS$ 18,650 - 39,650MOQ: 1 Set
The Main Structure Character:
Welded steel plate construction, eliminate internal stress by heat treatment, with high strength and good righty. Advanced integrate hydraulic system with an excellent reliability.
Rapidly, accurately and conveniently adjust the blade clearance with the hand wheel.
Feature and Advantages:
1. Hydraulic driven, welding blade body, whole machine structure welding with good rigidity and strength.
2. Gas return structure moves smooth and swift, hydraulic return is available, with lower noisy and stable working performance.
3. Cutting stroke could be adjusted when cutting different length plate, both up and bottom blade have 4 usable edges.
4. Plate clamping fixture uses independent hold down cylinder. There is plastic pad on the bottom of each cylinder to protect the plate being scratched.
5. CNC controller is close loop control system, fast speed, high accuracy, good stability; guarantee the accuracy of back gauge movement. Furthermore, the system has the function of compensation and auto inspection and so on.
6. Ball screw on the back gauge, moving without gap.
Hydraulic Shear Machine QC11K series Technical parameter
| Model | Cutting | Cutting | Throat | Back Gauge | Cut Angle | Strokes | Main Motor | Dimensions |
| Thickness | Length | Depth | Range | Per Minutes | (KW) | (LxWxH) | ||
| (450Mpa) | (mm) | (mm) | (mm) | (MM) | ||||
| QC11K 4x2000 | 4 | 2000 | 80 | 600 | 0.5°~2° | 14 | 5.5 | 2600x1680x1750 |
| QC11K 4x2500 | 4 | 2500 | 80 | 600 | 0.5°~2° | 14 | 5.5 | 3125x1750x1765 |
| QC11K 6x2500 | 6 | 2500 | 80 | 750 | 0.5°~1°30′ | 14 | 7.5 | 3100x1725x1900 |
| QC11K 6x3200 | 6 | 3200 | 80 | 750 | 0.5°~1°30′ | 12 | 7.5 | 3935x1840x1995 |
| QC11K 6x4000 | 6 | 4000 | 80 | 750 | 0.5°~1°30′ | 10 | 7.5 | 4650x1840x2100 |
| QC11K 6x5000 | 6 | 5000 | 80 | 750 | 0.5°~1°30′ | 8 | 7.5 | 5650x2050x2400 |
| QC11K 6x6000 | 6 | 6000 | 80 | 750 | 0.5°~1°30′ | 8 | 7.5 | 6650x1980x2380 |
| QC11K 8x2500 | 8 | 6000 | 80 | 750 | 0.5°~2° | 14 | 7.5 | 3135x1840x2075 |
| QC11K 8x3200 | 8 | 3200 | 80 | 750 | 0.5°~2° | 12 | 7.5 | 4650x2030x2075 |
| QC11K 8x4000 | 8 | 4000 | 80 | 750 | 0.5°~2° | 10 | 7.5 | 4650x2030x2075 |
| QC11K 8x5000 | 8 | 5000 | 80 | 750 | 0.5°~2° | 7 | 15 | 5650x2050x2400 |
| QC11K 8x6000 | 8 | 6000 | 100 | 750 | 0.5°~2° | 7 | 15 | 6805x2115x2715 |
| QC11K 10x2500 | 10 | 6000 | 100 | 750 | 0.5°~2°30′ | 10 | 15 | 3195x1915x2205 |
| QC11K 10x3200 | 10 | 3200 | 100 | 750 | 0.5°~2°30′ | 8 | 15 | 3895x1900x2235 |
| QC11K 10x4000 | 10 | 4000 | 100 | 750 | 0.5°~2°30′ | 6 | 15 | 4965x1970x2270 |
| QC11K 10x5000 | 10 | 5000 | 100 | 750 | 0.5°~2°30′ | 5 | 15 | 5700x2115x2800 |
| QC11K 10x6000 | 10 | 6000 | 100 | 750 | 0.5°~2°30′ | 5 | 15 | 5700x2115x2800 |
| QC11K 12x2500 | 12 | 2500 | 100 | 750 | 0.5°~2°30′ | 10 | 15 | 6905x2115x2800 |
| QC11K 12x3200 | 12 | 3200 | 100 | 750 | 0.5°~2°30′ | 8 | 15 | 3195x2040x2210 |
| QC11K 12x4000 | 12 | 4000 | 100 | 750 | 0.5°~2°30′ | 6 | 15 | 4710x1950x2240 |
| QC11K 12x5000 | 12 | 2500 | 100 | 750 | 0.5°~2°30′ | 5 | 30 | 5750x2115x2800 |
| QC11K 12x6000 | 12 | 6000 | 100 | 750 | 0.5°~2°30′ | 5 | 30 | 7150x2300x3100 |
| QC11K 16x2500 | 16 | 2500 | 100 | 750 | 0.5°~2°30′ | 8 | 15 | 3215x1970x2340 |
| QC11K 16x3200 | 16 | 3200 | 100 | 750 | 0.5°~2°30′ | 7 | 15 | 3915x1970x2455 |
| QC11K 16x4000 | 16 | 4000 | 100 | 750 | 0.5°~2°30′ | 6 | 15 | 4715x2010x2590 |
| QC11K 16x5000 | 16 | 5000 | 100 | 750 | 0.5°~3° | 5 | 22 | 6000x2300x3000 |
| QC11K 16x6000 | 16 | 6000 | 100 | 750 | 0.5°~3° | 5 | 37 | 7250x2400x3100 |
| QC11K 20x2500 | 20 | 2500 | 100 | 750 | 0.5°~3° | 6 | 22 | 3235x2020x2465 |
| QC11K 20x3200 | 20 | 3200 | 120 | 750 | 0.5°~3° | 5 | 30 | 4150x2065x2755 |
| QC11K 20x4000 | 20 | 4000 | 120 | 750 | 0.5°~3° | 4 | 30 | 4955x2125x2885 |
| QC11K 20x5000 | 20 | 5000 | 120 | 750 | 0.5°~3° | 4 | 37 | 6000x2300x3050 |
| QC11K 20x6000 | 20 | 6000 | 120 | 750 | 0.5°~3° | 5 | 37 | 7150x2450x3280 |
| QC11K 25x2500 | 25 | 2500 | 120 | 750 | 0.5°~3.5°′ | 5 | 37 | 3465x2130x2710 |
| QC11K 25x3200 | 25 | 3200 | 120 | 750 | 0.5°~3.5°′ | 5 | 37 | 4120x2200x3000 |
| QC11K 25x4000 | 25 | 4000 | 120 | 750 | 0.5°~3.5°′ | 4 | 37 | 4950x2200x3150 |
We are devote to promoting overseas and domestic machinery development over 10 years of business trade and technology development in one of the high-tech enterprise.
Our company’s main business is focus on sheet metal processing machines tools and manufacture equipments, such as shear processing line, slitting line, laser cutting machine, CNC flame cutting machine, hydraulic bending machine, hydraulic cutting machine etc. The company has a strong research and development of high technology and quality professional R&D team, strong technical force, has a number of highly qualified development designers. Powerful, professional R&D team, advanced and perfect sales service concept, making our company’s products at home and abroad, have high visibility and market share. Meanwhile, we will continue adhering to the principle of reputation first, customer first, always put the customer’s interests first, wholeheartedly to offer each of our customers the best products and the best quality service.
Our products are widely exported to Asia, Africa, Australia, the Middle East, South America, Europe and other countries, has a good reputation, we also provide a range of service for equipment installation, technology consulting and support. We based on the spirit of large enterprises to build brand objectives, adhere steady and long-term operation.
Factory building
Workshop
Factory office
Why Choose Us?
1.Our guarantee time is 13 months from B/L Date ,If any component is damaged during guarantee time, we can send the component to the customer By DHL,TNT freely .
2.Our factory can send our engineer to the customer’s factory install, commission and training freely .The customer provide the double trip tickets, food and accommodation for our engineer. The customer also can send the engineer to our factory to learn the operation and maintains freely
3.Our factory provide the service for the customer forever, if the customer need operation help,can contact us by MSN, Skype, Email and Telephone at any time, we provide 24 hours on-line service
How about your machine quality?
Shenchong(SC) is a mature brand in CHINA,through our many years research in technology,our design including structure and detailed sercurity and precision has enhanced greatly,and can match all the CE standard or more strict standard.Our machines distribute worldwide to about 50 countries where there are metal plate industry ,there are SIECC machines.And where there are our machines,there are good reputation and terminal user satisfaction.
Whether the machine price can be more discount
Shenchong(SC) always provide high quality machine,as we know ,oversea market is more important and difficult than domestic market because of communication time costing after sales,So always,our machine has enough qaulity standard to make sure the machine can work more than the real warranty period.In this way ,we will save a lot and think in advance for the clients.
Actually Shenchong(SC) also think about our price level,we are sure to provide quality=price and pice=quality ,the matched price and acceptable for the clients and durable for our machines.We welcome your negotiate with us and get a good satisfaction.
Do you accept L/C payment term?
Yes,we accept 100% L/C at sign from almost all countries.
How to operate your machine?
Don’t worry,we have our company own CD/Manual to show you along with the machine.So you can learn this from the existing documents to deepen your knowledge and understanding. Anyhow there are another way is through internet video face to face for machine teaching, because of the high development in internet,the world has become smaller and you can easy catch us if any assistance needed .
