Help CenterOutdoor P20 DIP346 LED Display _O
US$ 1 - 20,000
MOQ: 50 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
China
Brand Name:
CEDAR
Model Number:
CD-WP20-DM
Payment & Shipping
Payment Methods:
Port of Shipment:
Dalian/Shenzhen/Ningbo/Qingdao/Lianyungang
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Outdoor P16 DIP346 LED Display _OUS$ 1 - 20,000MOQ: 50 Square Meters -
Outdoor P10 DIP346 LED Display _OUS$ 1 - 20,000MOQ: 50 Square Meters
-
Outdoor Small Pitch SMD LED Display _OUS$ 1 - 20,000MOQ: 5 Square Meters
-
Indoor SMD LED Display _B_OUS$ 1 - 20,000MOQ: 5 Square Meters
-
Indoor SMD LED Display _A_OUS$ 1 - 20,000MOQ: 5 Square Meters
Place of Origin
China
Brand Name
CEDAR
Model Number
CD-WP20-DM
Usage
Indoor
Tube Chip Color
Full Color
Display Function
Video
Pixels
20mm
Screen Dimension
Customized
Models & Parameters
| Parameters | WP20-DM | |
| Pixel | Pixel Setting | DIP 346 1R1G1B |
| Pixel Pitch(mm) | 20 | |
| Pixel Density(Pixel/m2) | 2500 | |
| Module | Module Resolution (W/Pixel × H/Pixel) | 16 × 8 |
| Module Size (W/mm × H/mm) | 320 × 160 | |
| Cabinet | Cabinet Resolution (W/Pixel × H/Pixel) | 64 × 48 |
| Cabinet Size(W/mm × H/mm) | 1280 × 960 | |
| Material | iron | |
| Cabinet Weight (kg/Pcs) | 70 | |
| Cabinet Area (m²) | 1.2288 | |
| Screen Weight (kg/m²) | 57 | |
| Cabinet Flatness (mm) | ≤1 | |
| Maintenance | front/rear | |
| Optical | Dot by Dot Calibration | support |
| Brightness (cd/m²) | ≥6500 (calibrated@9300K) | |
| Brightness Adjustment | 256 grades auto/manually adjustment | |
| Color Temperature (K) | 3000 — 10000 adjustable | |
| Horizontal FOV ( °) | 120 | |
| Vertical FOV ( °) | 60 | |
| Brightness Uniformity | ≥ 95% | |
| Electrical | Peak Power Consumption (W/m²) | 350 |
| Average Power Consumption (W/m²) | 120 | |
| Input Voltage (V) | AC110~240V(50-60Hz) | |
| System Process | Drive Mode | constant current (static) |
| Frame Rate (Hz) | 60 | |
| Refresh Frequency (Hz) | ≥ 2400Hz | |
| Grey Scale(Bit) | 16 | |
| Color Capacity(Trillion) | 281 | |
| Applications | Lifespan (h) | 80000 |
| Ingress Protection | IP65 | |
| Operation Temperature (℃) | -35 ~+50 | |
| Storage Temperature (℃) | -40 ~+85 | |
| Operation Humidity(RH) | 10% ~ 90%, with no condensation | |
| Storage Humimdity (RH) | 10% ~ 90%, with no condensation | |
| Others | Support on-site dot-by-dot calibration | |
| Support on-line signal dual direction backup | ||
| Available for being controlled by Cedar RTM Software | ||
| Available for different signal format, such as AV,S-Video,VGA,DVI,HDMI,SDI,DP | ||
| Parameters can be customized | ||
