Hot selling the wood chipper shredder in brazil 008615137127638
wood chipper machine is mainly used to crush big wood logs or timber
wood branches, furniture waste, long bamboo into small chips , the thickness of last chips is 1.5mm-3mm, length and width about 20-50mm, the knives gap can be adjusted, then outlet chips dimension will be adjusted.
-wood chipper machine contains 4m length feeding belt conveyor, when conveying logs, the speed can be adjusted. also it can connect with outlet conveyor to transport away crushed wood chips.
-Wood chipper machine has limit feeding door dimension, raw wood logs should be smaller than feeding door, but length no limit, feeding speed can be adjusted.
-The hydraulic system is consisting of oil pump, hydro cylinder, which can start up the cover for blades changes and maintenance.
Working principle of wood chipper:
According to the thickness of the different raw material, top feeding roll can move up and down with the help of hydraulic system. The qualified final product will be discharged from the sieve and then out of the base, the bigger pieces will be crushed in the machine again.
Hydraulic system:
Supply oil to cylinder by hand oil pump, you can start the cover shell for replace blades conveniently. When maintain and repair you can uplift the feeding roller assembly for good conveniently adjust the fly blades, bottom blades gap and dismantle comb plate
Features of wood chipper
1. This machine with advanced design and structure, processing high quality wood chips.
2. It is consist of main machine, knife roller, knife blades, feeder, conveyor, hydraulic pressure system, etc. Machine body is welded by high strength steel plate forming the integrated support base.
3. Knife roller with 2-4 knifes which can be adjusted up and down based on the thickness of wood chips required. Qualified chips come down through the screener and outlet, but big block will return to crushing room for second processing.
4. The hydraulic system is consist of oil pump, hydro cylinder, which can start up the cover for blades changes and maintenance.
5. The machine is suitable for processing of wood waste and other waste materials such as density board, straw etc.
Technical Parameters of wood chipper
Model | BX213 | BX216 | BX218 | BX218D* | BX2113 | BX2120* |
Knife Roll Diameter mm | 300 | 650 | 800 | 800 | 1300 | 2000 |
Blades | 2 | 2 | 2 | 2 | 2 | 3*2 |
Feed Port Size mm | 120*300 | 180*500 | 225*680 | 240*750 | 400*700 | 850*1,250 |
Knife Roll Speed rpm | 730 | 590/836 | 650 | 650 | 500 | 295 |
Feed Speed m/min | 38 | 37 | 37/25 | 38 | 38 | 31 |
Max. Working Material Diameter mm | 90 | 120 | 160 | 160 | 230 | 370 |
Chips Length mm | 26 | 30/22 | 30/20 | 30 | 38 | 35 |
Capactiy m3/h | 3-5 | 10 | 15-20 | 38 | 36-64 | 190 |
Power kw | 30 | 55 | 110 | 132 | 200-250 | 800-1,000 |
Feed Roller Motor Power kw | 1.1*2 | 3*2 | 4*2 | 4*2 | 7.5*2 | 22*2 |
Pump Motor Power kw | 1.1 | / | / | 0.55 | 3 | 3 |
Weight kg | 1,200 | 4,070 | 7,000 | 7,500 | 11,840 | 55,000 |
Dimension mm (L*W*H) | 3,680*870*900 | 4,348*1730*1,258 | 4,670*2,150*1,500 | 4,670*2,150*1,500 | 3,670*2,517*2,050 | 7,970*7,150*2050 |
1. Free tool box and free easy damage parts
2. Warranty: warranty time is 12 months after the goods delivery your port.
3. Color: according to your requirement
4. Logo: can stick your logos free if you need
5. Delivery time: 25 days after the down payment
6. Payment: The payment term is T/T (30% deposit in advance, 70%T/T as balance before shipment)
7. Spare parts are supplied too for your machine if you need
8. technical service offered whenever you are in need
1) Pre-sale Service:
Design suitable product, offer reasonable consultation and referring documents.
2) After-sale Service:
On the spot guidance for installation by our enginee, and the buyer is responsible for the Expense. We have perfect after-sales service system and team with professional advice and guidance for whole using life.
3) All order will be supplied within the stipulated period.
Spare parts:
1.Special blade knife material: 55si6 Spring Steels
2.Use famouse spare parts to guarantee the pellet mill quality: (siemens motor, SKF/NSK bearing)
Welcome to our factory, i can show you live plant and machines.
Kindly contact me, thanks
Manager: Victor phone no. +8615137127638
Skype: chinavictor6688
