Help CenterPortal Digital Leeb Hardness Tester SHL-360
Related Products
-
Portable Hardness Tester PriceNegotiableMOQ: 1 Set -
China Manufacturer Portable Steel Hardness TestersNegotiableMOQ: 1 Set
-
Digital Leeb Hardness Testers PortableNegotiableMOQ: 1 Set
-
Portable Hardness Tester Suppliers & Exporters in ChinaNegotiableMOQ: 1 Set
-
Portable Hardness Testers Leeb UltrasonicNegotiableMOQ: 1 Set
Specifications
1.portal ,convenient2.Multifunctional
3.Beast price
4.Manufacture
Approved by CE certificate, ensure the safety operation of the machine. Certificate No.: GB/1067/3980/12 Issue 1.
SHL-100 Pen type Leeb hardness tester according to the Leeb hardness measurement principle can be easily and quickly measure a variety of metal materials, and instantly display the value of measured hardness. And it can swiftly convert the hardness value in different hardness scales.
1. Technical parameters:
1) Measuring range:
(170-960)HLD,(17-68.5)HRC,(19-651)HB,(80-976)HV,(30-100)HS,(59-85)HRA(13 -100)HRB
2) Measuring direction:
Support 360º testing (Vertically downward, oblique, horizontal, oblique, straight up)
3)Hardness scale:
HL,HB,HRB,HRC,HRA,HV,HS
4) Display
High resolution dot matrix LCD, LED backlight
5) Data storage
Max 500 groups (relative to impact times 32~1)
6)Working power
3.6V (built-in lithium battery and charging circuit)
7) Continuous working period: about 100 hours(With backlight off)
8) Communication interface: USB1.1
2. Applicable to materials
Steel and cast steel, alloy tool steel, stainless steel, gray iron, ductile iron, cast aluminum alloy, copper-zinc alloys (brass), copper-tin alloy (bronze), copper, forged steel.
3. Working conditions:
Circumstance temperature: Operation temperature -20---+60C;
Keeping temperature: -30C—+60C
Relative humidity ≤ 90%
The surrounding environment without a strong vibration, strong magnetic field, non-corrosive medium and severe dust.
4. Configuration
1) Host 1 set
2) Sensor 1 piece
3) Nylon brush 1 piece
4) Small support ring 1 piece
5) Manual book 1 piece
6) ABS Equipment cabinet
