OEM patch cord Cat.5e, Cat.6
- 10 Piece / Pieces per Month
- ningbo or shanghai
- T/T L/C D/P D/A
- Special cables and wires for airport technology
- This temperature probe is versatile due to its design and high temperature resistance.
- We manufacture cable assemblies according to your special requirements.
- DNV-GL Type Approval, suitable for offshore applications, extrem highly winding and unwinding strength, small outer diameter
- The silicone connection cable 4 x 2 x 0.22 msqm is especially used as a connection between laptop and thermo module.
- This Multi Bus Cable with PUR outer sheath, moulded socket, and male connector is especially suited for robots.
Product Details
Brand Name: | GYA | Model Number: | OEM patch cord | Place of Origin: | Zhejiang, China |
Use: | Other, Computer |
Product Description
Specifications
1) OEM patch cord Cat.5e, Cat.62) Channel test by fluke
3) Modular plug from F to 50u"
4) PVC/LSOH
5) RoHS/UL
WELCOME to JINHUA GUANYANG~~!!
1. Curious about how to produce one patch cord?
1. Specification:
1) Cat5e patch cord:
Cable | Cat.5e UTP or FTP cable |
Jacket | PVC/LSZH jacket |
Wire | 4*2*AWG24/26, Twisted Pair |
Plug | RJ45 Gold plating from FU” to 50U” |
Transmission | It supports data transmission to 100MHz |
2) Cat6 patch cord:
Cable | Cat.6 UTP or FTP cable, with Cross inside |
Jacket | PVC/LSZH jacket |
Wire | 4*2*AWG24/26, Twisted Pair |
Plug | RJ45 Gold plating from FU” to 50U” |
Transmission | It supports data transmission to 250MHz |
3) Cat6A patch cord:
Cable | Cat.6A SSTP(PiMF) cable |
Jacket | PVC/LSZH jacket |
Wire | 4*2*AWG26, Twisted Pair |
Plug | RJ45 50U" Gold plating |
Transmission | It supports data transmission to 500MHz |
3. Testing:
1) Normal test-----channel test:
2) Strict test----component test: Our patch cords can be individually tested by strict component test and comes with test results in every bag.
4. How we do Quality Control:
1) Importing QC:
2) In-process QC:
3) Outgoing QC:
5. Certificates:
UL and RoHS.
6. Packing:
1) Packing Rate:
Length | Q'ty/CTN Cat.5e UTP | Q'ty/CTN Cat.5e FTP | Q'ty/CTN Cat.6 UTP | Q'ty/CTN Cat.6 FTP | Q'ty/CTN Cat.6A SSTP | Carton dimension |
0.5M | 350 | 350 | 300 | 300 | 300 | 400*380*290CM |
1M | 250 | 200 | 200 | 200 | 200 | 400*380*290CM |
2M | 200 | 150 | 150 | 150 | 150 | 400*380*290CM |
3M | 150 | 100 | 100 | 100 | 100 | 400*380*290CM |
5M | 80 | 70 | 70 | 70 | 70 | 400*380*290CM |
10M | 40 | 40 | 40 | 36 | 35 | 400*380*290CM |
2) Neutral packing:
3) Special packing:
