Specifications
injection plastic machine has1.thick platen ,
2.long ejector stroke .
3.stable and precise
We are electricity saving machine injection Chinese supplier with more than 10years experience in injection plastic machine area,now we have developed several types of injection plastic machine ,including
1.energy saving injection machine ,
2.standard type injection machine
3.high speed injection machine.
and we are professional in making special machine like
1.PVC injection machine ,
2.bakelite injecton machine
3.,BMC injection machine ,
4.rubber injection machine,etc.,
the injection capacity is from 63g to 10000g , clamp force is from 68ton to 1680ton .
|
INJECTION UNIT |
|
Unit |
LSF-620 |
||
A |
B |
C |
|||
Screw Diameter |
Mm |
90 |
95 |
100 |
|
Screw L/D Ratio |
L/D |
21.1 |
20 |
19 |
|
Short Size |
Cm3 |
2670 |
2970 |
3290 |
|
Injection weight |
G |
2430 |
2700 |
3000 |
|
Injection Rate |
g/s |
470 |
530 |
580 |
|
Plasticizing capacity |
g/s |
75 |
88 |
110 |
|
Injection Pressure |
Mpa |
184 |
165 |
149 |
|
Screw Speed |
Rpm |
0-125 |
|||
|
CLAMPING UNIT |
Clamp Force |
KN |
6200 |
||
Space Between Tie Bars |
mm |
840*820 |
|||
Toggle Stroke |
mm |
845 |
|||
Max. Mold Height |
mm |
860 |
|||
Min. Mold Height |
mm |
350 |
|||
Ejector Stroke |
mm |
220 |
|||
Ejector Tonnage |
KN |
150 |
|||
Ejector Number |
P |
13 |
|||
|
OTHERS |
Max. pump Pressure |
Mpa |
16 |
||
Pump motor powder |
Kw |
55 |
|||
Heater Power |
Kw |
25 |
|||
Machine Dimension(L*W*H) |
M |
9*2.3*3 |
|||
